Motorhome water Pumps

The Jabsco Xylem Par-Max HD4 12V DC freshwater delivery pump features a wide diameter motor (compared to non-HD models) with a powder-coated shell, cast aluminium endbells and lower housing to improve pressure capability and life. The pump delivers exceptional performance and has a dry self-priming capability of 2.13 meters (7ft) and can run dry without damage. It is designed to serve four or more outlets. Pump features include vibration-dampening feet for quiet operation and an integrated, sealed pressure switch for on-demand operation. The pump is supplied with two 1/2” quick connect straight hosebarb fittings and a quick connect inline 40 mesh strainer. • Voltage: 12V DC • Open flow GPM (LPM): 4 (15) • Shut-off pressure PSI (BAR): 40 (2.8) • Max. current AMPS: 10.0 • Recommended fuse size: 15 • Port fittings: 2 x 1/2" Straight Hosebarb • Dimensions: 9.4” in length, 4.1” in width, 3.8” in height / 239(L) x 104(W) x 97(H)mm Replaces 509737 Self Primes up to Up to 8ft (2.4m) dry prime Inlet Outlet Fittings for 13mm (1/2") ID hose Brand Jabsco Type Fresh Water Pumps Voltage Description 12V DC Model Q401J-115S-3A Size Leads: 12" (305mm), 14 AWG (2.5mm^2) Height Description 97mm Width 104mm Depth 239mm Weight 2.94kg Fuse 15A (not included) Temperature Range Ambient & Fluid: 0°C to 60°C (32°F ‐ 140°F) Flow Rate Description 15 LPM (4 US GPM) Approvals ISO 8846 Ignition Protected, C.E Certified, RCM compliant Pressure Rating Operating: 40 PSI (2.8 bar) maximum, Inlet: 30 PSI (2.1 bar) maximum Amps Description 10 Amps at 40 PSI (2.8 BAR) Supplied With Inline Strainer (40 mesh) & Quick Connect Fittings Cut In Pressure 35 PSI Cut Out Pressure Description 40 PSI / 2.8 Bar Downloads Jabsco Par Max Series Brochure en Technical Data Sheet Jabsco Xylem Par Max HD4 Q401J 115S 3A

Read more less

OEM version of the 26500 pump - It does not include retail packaging, fittings or connectors. Shurflo Trail King are fully automatic triple diaphragm positive displacement freshwater pumps with integral pressure switch. • Quiet Performance • Runs dry without damage • Self Priming • Built-in Check Valve • Easy Installation • Enclosed Motor • Thermally Protected Key Features Quiet Performance Runs dry without damage Self Priming Built-in Check Valve Easy Installation Enclosed Motor Thermally Protected Brand SHURflo Type Fresh Water Pumps Voltage Description 12V DC Model Trail King 7 Flow Rate Description 7LPM Cut Out Pressure Description 20 PSI / 1.4 Bar

Read more less

OEM version of the 26502 pump - It does not include retail packaging, fittings or connectors. Shurflo Trail King are fully automatic triple diaphragm positive displacement freshwater pumps with integral pressure switch. • Quiet Performance • Runs dry without damage • Self Priming • Built-in Check Valve • Easy Installation • Enclosed Motor • Thermally Protected • Light duty (vehicle/motorhome) leisure use. Key Features Quiet Performance Runs dry without damage Self Priming Built-in Check Valve Easy Installation Enclosed Motor Thermally Protected Brand SHURflo Type Fresh Water Pumps Voltage Description 12V DC Flow Rate Description 7 LPM (1.8 US GPM) Cut Out Pressure Description 30 PSI / 2 Bar

Read more less

Whale's manual galley pumps are truly design classics. Since the 1960s these manual pumps have been designed, refined and manufactured by our skilled UK based workforce. Self priming Lever operated hand pump. Ideal for installing between two sinks- swivelling outlet fine flow control. 7 litres capacity per minute Key Features Easy operation Light back & forth pump action Suitable for fresh watered saltwater Brand Whale Type Cold Tap Model Flipper MK4 Height Description Overall: 304mm Width Body: 61mm Depth Body: 103mm Finish Aluminium Material Aluminium Alloy Outlet Colour Aluminium Diameter Description Base: 54mm Application 13mm Inside Diameter Hose Capacity Description 7 LPM Country of Origin United Kingdom Downloads Whale Pump Brochure Whale Pump Brochure

Read more less

Whale Gulper 220 is a wastewater pump particularly designed to handle hair and gels, making it ideal as a shower waste pump. It features a body constructed from aluminium and glass-filled nylon for a robust housing suitable for the marine environment along with rubber feet designed to absorb vibration. Popular diaphragm pump, will run dry without damage and self priming up to 3m. Multi-directional head. Up to 14 litres per minute. Dimensions: 117mm x 173mm (including hose tails) x 273mm Connections Type: 19mm hose tails Fuse Requirement: 5A. Maximum Pump Head 2.3 to 4.27 Metres Dimensions Base: 135mm x 111mm (5-5/16" x 4-3/4") Maximum Combined Head and Lift 4m (13.1ft) Maximum Recommended Head 3 Metres (9.8 Feet) Replaces Closest Alternative for 509430 & 509432 Flojet Shower Waste Drain Pumps Self Primes up to 3 Metres (9.8 Feet) Wire Size Minimum 1.5mm² (16 AWG) Inlet Outlet 19mm (3/4") ID hose Brand Whale Type Toilet Pumps Voltage Description 12V DC Model BP1552 Height Description 117mm (4-5/8") Width 173mm (6-13/16") Length 273mm (10-3/4") Fuse 5A Flow Rate Description 14 LPM (3 GPM / 3.7 US GPM) Approvals CE Marked, IP45 rated for water ingress, Ignition protected ISO8846, ISO10133 Electrical systems – extra low voltage dc installations Warranty 2 Years Country of Origin United Kingdom Downloads Installation Sheet Product Sheet Technical Article - Waste Tanks & Kits

Read more less

Enamelled steel with stainless steel flange and internal rubber membrane. Can be mounted in any attitude. Brand Jabsco Type Accumulator Tanks Height Description 230mm (9") Width 200mm Depth 220mm Capacity Description 8 Litres (2.1 US Gallons) Connections Description 3/4" BSP Working Pressure 4 bar (60psi)

Read more less

The Fiamma A20 expansion tank is designed to enhance the performance of water pumps in various systems by eliminating pulsating pump operation. This helps achieve a smooth and continuous flow of water rather than intermittent bursts. By providing a constant flow of water, the A20 expansion tank contributes to reducing water consumption. The tank's internal diaphragm absorbs water hammer (the pressure surge or shockwaves caused by the sudden stop or change in the flow of water). This helps in preventing damage to the pump and associated components. This 2024 A20 expansion tank has a black finish and is compatible with all Fiamma pumps and other non-Fiamma pumps. Key Features Ensures a smooth and continuous flow of water for improved water distribution Contributes to reduced water consumption Internal diaphragm absorbs water hammer Compatible with all Fiamma pumps and other non-Fiamma pumps Brand Fiamma Type Fresh Water Pumps

Read more less

The Truma Ultraflow pump assembly is an ergonomic and simple solution to enable you to easily pump water into your vehicle from an external source. It conveniently connects with your Aqua roll or Water hog and is compatible with both the Ultraflow Filter Housing and the Ultraflow Compact Housing. (46040-01). 1.2 bar Brand Truma Type Water Pump Voltage Description 12V DC Length Hose: 800mm Flow Rate Description 9 LPM

Read more less

The Geo submersible pump from Comet. • Supply: 12V • Delivery height: max. 7m (0.7 bar) • Cable length: 1m • Power consumption: 15 - 25 W • Delivery rate: max. 14L / min • 42mm (dia) / 125mm (h). Maximum Recommended Head 6.5 Metres Brand Comet Type Water Pump Voltage Description 12V DC Height Description 125mm (4.9") Length 1M Flow Rate Description 14 LPM Diameter Description 42mm Consumption 15-25 w Downloads Data Sheet

Read more less

Extremely high quality submersible pump. Designed with two motors inside, which ensures exceptional power with regard to water flow and pressure. In the event of one of the motors failing the Twin pump will still work! 12V – 19L/min – 1.4Bar – 55W. Necessary tank opening 80mmø. Complete with 1M of cable and integrated non-return valve. Brand Reich Type Water Pump Voltage Description 12V DC Length 1M Flow Rate Description 19 LPM Diameter Description 80mm Consumption 25-55 w

Read more less

Quality inline booster pump made by Reich. 15L/min - .5Bar 10-20W consumption. Necessary tank opening 46mmø. Complete with 1m of cable. Brand Reich Type Water Pump Voltage Description 12V DC
