London Mixer Tap
The modern unit for a build in high of under 40 mm. An eye catching unit for kitchen or bathroom.
With microswitch. Warm water resistant. Max. pressure level 1,5 bar.
Outlet Foldable
width / height/ depth:
57 / 87 / 40 mm (outlet folded in)
mounting hole:
27 mm
thread length:
25 mm
thread
3/4"
connection:
hose-tail 10 mm
FEATURES
The fabric slides into the awning lead rail
All panels can be rolled up and are fixed with a side release buckle
The Thule Rain Blocker G2 panels can be combined with smart connections
Durable fabric material: top quality PVC
TECHNICAL SPECIFICATIONS
Compatibility
Most Vehicles
Materials
Transparent PVC-fabric
Weight
2 kg
SIZING Guide PDF PLEASE CLICK ME!
Please see Fitting Instructions down Below:
Thule Rain Blocker G2 Front Fitting Instructions
Additional Information
Thule Rain Blocker G2 front Fitting Instructions Video
Finally, a sturdy compact roof light not only admits just the right amount of light into the interior but also includes optional forced ventilation for plenty of fresh air. Separately adjustable darkening and fly screens offer privacy and enforce the no-fly zone!
Dimensions product depth 520 mm
Dimensions product width 520 mm
Net weight 2.90 kg
Cut out height 400.00 mm
Cut out width 400.00 mm
Positions fixed 5
Using handles, it can be placed in five different positions
Separately adjustable darkening and fly screens keep light and insects out
Forced ventilation
Dome with single acrylic glazing
400 x 400 mm
Documentation & Downloads
Dometic Mini Heki S - Figures and Installation and Operating Manual EMEA16
ADAPTER FRAME FOR MIDI HEKI, 700 X 500 MM
FOR FRONT OF DUCATO VAN
Hassle-free installation
Designed for Midi Heki roof lights
For opening size of 700 x 500 mm
Documentation & Downloads
Dometic Midi Heki Adapter Frame for Fiat Ducato Front Installatin Manual
For easy entrance into your recreational vehicle.
Features
Locked in closed position
Installation brackets: different heights: 9/35/62/88mm
Rounded corners which glow in the dark
Made of corrugated anodised aluminium
Technical specifications
Compatibility
Caravans
Materials
Corrugated anodised aluminium
Step width
406 mm
Total width
485 mm
Operation
Manual
Weight
4.7 kg
NB.No van installation kits are available for this step
Made from stainless steel, 2-burner gas supply, equipped with left-hand rectangular sink, stainless steel support grid fixed with anti-vibration grommets.
Double lid in tempered black glass, divided between cooking area and sink, with concealed hinges.
NUMBER OF BURNERS
2
POWER
A 1 kW / SR 1,9 kW
POWER SUPPLY
LPG 28-30 mbar
CONSUMPTION
(A 73g/h) (SR 127g/h)
SAFETY DEVICE
Thermocouple
IGNITION
Piezo ignition
MATERIAL
Stainless steel 304 L
FINISH
Satin finish
PRODUCT SIZE
716x340x150mm
BUILT-IN SIZE
696x325mm
FIXING KIT
Included
NET WEIGHT
6 kg
PLATE
CE
WARRANTY
2 years
Quick and easy way to carry all types of watersports gear safely and securely.
Ideal for carrying surfboards, SUPs, sailboards
Boards and boats are well protected during transport with these high density foam pads
Long lasting performance with durable 600D nylon construction with UV resistance
To be used with Thule Locking Straps or Thule Load Straps
Easy on and off with hook and loop closure design along bottom of pads
Integrated no-slip grip on top of pads keeps loads in place
Dimensions
51 x 8 x 8 cm
Weight
0.68 kg
Lockable
✖
Fits Thule WingBar Evo
✓
Fits Thule WingBar
✓
Fits Thule SlideBar
✖
Fits Thule SquareBar
✖
Fits Thule ProBar
✓
Model number
845000
Functional bike rack fulfilling all basic needs (for 2 bikes).
Features
Trunk access with bikes mounted, thanks to hand-operated tilt
Quick mounting of bike rack, thanks to the smart tightening handle
Bikes mounted to bike rack via stable frame holders
Fastening of wheels with soft straps
Locks the bike rack to the towbar (lock included) and the bikes to the bike rack with the lockable knob accessory
Technical Specifications
Max number of bikes
2
Load capacity
36 kg
Max bike weight
20 kg
Dimensions
105 x 58 x 75 cm
Folded dimensions
105 x 67 x 25 cm
Weight
14 kg
Fits frame dimensions
22-70 mm
Detachable frame holders
✖
Distance between bikes
17 cm
Carbon frame compatible
✖
Wheel mounting on adjustable holders
Adjustable straps
Tilt function (with bikes)
✓
Fits cars with exterior spare tyre
✖
Rear lights
✓
Power connector
7-pin
One Key System compatible
✓
Lockable bike-to-rack
✓ Adapter/s required: Thule Lockable Knob
Lockable rack-to-vehicle
✓
Model number
941005
Warranty
Thule is dedicated to providing exceptional products that are quality tested and guaranteed against defects in materials and workmanship.
Sigma S34
PLEASE NOTE THE BELOW:
As a insurance requirement a registered Scorpion installer/Dealer has to do the installation. Upon purchase details will be sent to a local installer/dealer in your area installation price dependent on vehicle.
Thatcham Category 2-1 upgrade alarm system, with new radio keys, providing perimeter and ultrasonic interior protection.
Thatcham Category 2 to 1 upgrade alarm system, providing perimeter and ultrasonic interior protection
Supplied with 2 x single button radio keys, self powered siren and tri-coloured status LED
The system has full, in-built, CDL control to power/switch a vehicle’s CDL system
Single immobilisation circuit
Key theft protection facility - only with optional keypad
Auxiliary siren, armed accessory, total closure, interior lamp illumination, headlamp illumination, 2-stage unlock and boot release or remote engine start/stop outputs (separate module required)
Sophisticated programming and diagnostic facility via either the keypad or a CP3 workshop programmer
Security Features
2 x single button radio keys (programmable, water and shock resistant with random 66-bit encryption to prevent scanning and code grabbing. Lost or stolen radio keys can be programmed out)
Perimeter protection circuit for boot and bonnet (negative input)
Perimeter protection circuit for doors (positive or negative input)
Closed loop protection circuit (looped wire to protect accessories, trailers, bike racks etc)
Ignition detection circuit
Ultrasonic interior protection (base sensitivity adjustable, length of disturbance adjustable and automatically adjusts if any movement is detected during the threshold time)
Single immobilisation circuit (18 amp continuous/30 amp max)
Manual arm, using the radio key (or programmable auto arm, which automatically arms the system 60 seconds after the last door is shut - adjustable between 1 and 99 seconds. Auto arm can also be programmed to lock the vehicle if required)
Auto re-arm can be programmed to re-arm the system if a door is not opened within 60 seconds of disarming the system -adjustable between 1 and 99 seconds. Auto re-arm also re-locks the vehicle
A Key theft protection feature can be turned on to prevent the radio keys automatically de-activating the immobilisation when the alarm system is disarmed. In this mode the systems PIN must also be entered into the keypad before the vehicle can be started. This prevents the theft of a vehicle even with the owner’s keys
Last trigger identification via the dashboard LED and a record of the elapsed time since the last trigger can be recalled using the keypad or a CP3 workshop programmer
The total trigger count memory for each individual circuit since the system was installed or the memory re-set is also stored in the system's memory
Additional plug in single stage sensor socket (see optional accessories)
Additional plug in dual stage sensor socket and siren pre-warn facility (see optional accessories)
Secure data linked, self powered siren included
Convenience Features
Full central door locking/unlocking control (with the ability to adjust the pulse length, to provide a double pulse or adjust the delay period)
Armed output (negative 200mA max)
Additional siren/pager output (negative 200mA max)
Total closure output (via holding down the radio key when arming or for a timed period with the ability to adjust the pulse length, to provide a double pulse or adjust the delay period – negative 200mA max)
Total open/boot release output (via holding down the radio key when disarming or for a timed period with the ability to adjust the pulse length, to provide a double pulse or adjust the delay period – negative 200mA max)
Interior lamp illumination output (negative 200mA max)
Headlamp illumination output (negative 200mA max)
Secure ignition PIN override
Secure PIN override using the keypad
Silent arm and disarm (audible bleeps can be programmed back on, however this will breach current legislation)
The last circuit to trigger can be excluded using the keypad
The vehicle’s battery voltage can be checked using the keypad
The sensors are excludable using the keypad, ignition or remotely with the optional two button radio key
Personal Safety Features
Auto lock can be programmed to lock the vehicle at the start of a journey when the ignition is turned on, and then unlock when the ignition is turned off. This can be excluded on individual occasions
Two stage unlock can be configured to only unlock the driver’s door when the system is disarmed, the remaining doors are only unlocked if the radio key is pressed a second time
Panic feature switched using the radio key and or an optional internal button
S34 Box ContentsS34 alarm ECUECU brackets and fixing screwsS34 alarm installation wiring loom8-wire accessory wiring loomSecure data linked, self powered sirenSiren lead with plug with bonnet switch wireSiren bracket and fixingsTri-colour LED and loomTwo ultrasonic heads, looms and fixingsTwo radio keysOperating instructions and PIN stickersCertificate of installationTwo Sigma window stickersSheet of remaining foil stickers
Optional Accessories
T-TS1
Tilt sensor. Plug in sensor. Only for use in addition to the ultrasonic interior sensors
AS610
Single stage shock sensor. Plug in sensor. Only for use in addition to the ultrasonic interior sensors
AS620
Single zone microwave. Plug in sensor. Only for use in addition to the ultrasonic interior sensors
Dual Stage Sensors
AS625
Dual zone microwave. Plug in sensor. Only for use in addition to the ultrasonic interior sensors
T2SS
Dual stage shock sensor. Plug in sensor. Only for use in addition to the ultrasonic interior sensors
Other
2012054
RF pager
SIGAC22M
2 window closer module
SIGACTBC
Two button radio key conversion kit
Quality and Approvals
Thatcham “Category 2 to 1” approved for passenger cars:
TC2 – 1299/0204
Thatcham “Category L2 to L1” approved for light commercial vehicles:
TUL1-106/0304
EU 95/56 directive (security) and EU 95/54 directive (electrical) – “e” marked: Two year warranty
E1 A-00 0475
Feature table
Feature
S4
S30
S32
S34
Method of Arming
Radio
Radio
OE
Radio
Immobilisation Circuits
1
2
1
1
Key Theft Protection (via Keypad)
Y
Y
Y
Y
Auto-arm Auto-rearm (Passive Arming)
Y
Y
Y
Y
Ignition Detection Circuit (or Internal Panic Button Facility)
Y
Y
Y
Y
Door "+" Protection Circuit
Y
Y
Y
Y
Door "-" Protection Circuit
Y
Y
Y
Y
Combined Boot/Bonnet "-" Protection Circuit
Y
Y
Y
Y
Closed Loop Protection Circuit (or Internal Panic Button Facility)
ACC 8
ACC 8
ACC 8
ACC 8
Ultrasonic Interior Sensors
Y
Y
Y
Y
Additional, Single-stage Sensor Socket
-
Y
Y
Y
Additional, Dual-stage Sensor Socket with Pre-warn Facility
-
Y
Y
Y
Ultrasonic Interior Sensor Disable Facility
Y
Y
Y
Y
Sensor/s Disable Facility:
1= via Keypad (optional)
1
1
1
1
2= via Ign & Radio Key
2
2
2
3= via Ign & Inhibit Input
3
4= remotely via 2 Button Radio Key (optional)
4
4
4
5= remotely via OE repeated arm/disarm
5
Facility to Upgrade to Two-Button Remote
Y
Y
-
Y
In-built Central Door Locking Control (Full)
FULL
FULL
NEG
FULL
Total Closure from Extended CDL Pulse
Y
Y
-
Y
Alarm Armed Output*
ACC 1
ACC 1
ACC 1
ACC 1
Additional Siren / Pager Output**
ACC 2
ACC 2
ACC 2
ACC 2
Total Closure Output*:
ACC 1
ACC 3
-
ACC 3
1= Timed output on every arm.
1 or 2
1 or 2
2= Output whilst button 1 held on arming
2 only
Boot Release / Total Open Output
ACC 2
ACC 4
-
ACC 4
1= Timed output on every arm
1 or 2
1 or 2
2= Output whilst button 1 held on disarming OR
2 only
Remote Engine Start / Stop Output (Additional Module Required)
-
ACC 4
ACC 4
3= When button 1 & 2 held together
or 3
or 3
Interior Light Illumination Output
-
ACC 5
ACC 5
ACC 5
Headlight Illumination Output
-
ACC 6
ACC 6
ACC 6
Second Stage Unlock Output
-
ACC 7
-
ACC 7
Hazard Light Signalling
Y
Y
Y
Y
LED Colour
RED
TRI-COLOUR
TRI-COLOUR
TRI-COLOUR
Trigger Identification Via LED Flash-back
Y
Y
Y
Y
Battery Back-up Data Siren (Thatcham)
-
Y
Y
Y
High-power Audio Siren
Y
-
-
-
External Panic Facility from Remote
Y
Y
-
Y
Ignition Operated PIN Override
Y
Y
Y
Y
Ignition Operated Radio Key Teaching
Y
Y
-
Y
Facility to Connect Keypad
Y
Y
Y
Y
Facility to Connect Keypad / Touch Key Override
Y
Y
Y
Y
*On S4 models only the alarm armed output and the total closure output are mutually exclusive as they both use the acc 1 wire**On S4 models only the aux siren/pager output and the total open/boot release output are mutually exclusive as they both use the acc 2 wire
When it comes to ensuring your caravan or motorhome is in top condition, you need a reliable sealant that will protect it from the elements and prevent any leaks. That's where Sikaflex 522 comes in. This sealant is specifically designed for use on caravans and motorhomes, providing a secure and long-lasting bond that will keep your vehicle safe and dry.
One of the key features of Sikaflex 522 is its excellent UV resistance, meaning it won't break down or degrade when exposed to sunlight, ensuring a durable seal that will stand the test of time. Plus, its flexible nature allows for movement without compromising the bond, making it perfect for use on vehicles that are constantly on the move.
Key Features:
Specifically designed for caravans and motorhomes
color for a seamless finish
Excellent UV resistance for long-lasting durability
Flexible formula allows for movement without compromising the bond
Easy to apply and quick drying for convenience
Don't take any chances when it comes to protecting your caravan or motorhome. Invest in Sikaflex 522 today and rest easy knowing your vehicle is sealed with the best.
