Bostik Simson STR 360 Structural adhesive, enables you to fix your solar panel to a variety of surfaces including caravans and motorhomes without the need to drill any holes! STR 360 is a Silyl Modified Polymer (SMP) based adhesive with a high tensile strength and is suitable for making elastic constructive joints.
Applications
Elastic bondings and sealings in e.g. bus-, caravan- and trailer construction.
Bonding of metals, glass and plastics.
Features
Colour: White
Cartridge Size: 290ml
Silyl Modified Polymer
Solvent-, isocyanate- and PVC-free.
Good UV-resistance and ageing properties.
Permanently elastic in a temperature range of –40°C to +90°C
In general, STR 360 adheres well without primer on clean, dry, dust- and grease-free substrates of aluminium, stainless steel, galvanised steel, zinc, copper, brass, powder-coated metal, most lacquered metal surfaces, glass, PVC, polyester (GRP), painted and lacquered wood, etc. No adhesion on untreated polyethene, polypropylene and Teflon. In case of high adhesion demands the use of Simson Prep M is recommended. Prep M degreases and prepares the surface of the substrate in one step. On plain, untreated wooden surfaces and other porous substrates, Simson Prep P is recommended. In case the joint is exposed to UV radiation the bond surface has to be protected by UV-blocking methods like Simson Prep G. For more details concerning Prep M, Prep P and Prep G consult the specific technical information data sheets. For not mentioned substrates and additional information consult Bostik.
For more info please download the link below
Datasheet1
Our digital multitester offers 19 testing ranges and 7 functions. The Digital multitester is a really useful tool to have around when installing solar panels as damaged caused by reversed polarity is very common place during setup, it is very easy to check polarity with the multitester eliminating the risk of damage to the solar panel and associated components.
Check bulbs, fuses and batteries with ease.
Specifications
Power Supply: 9Vdc (1 x PP3 supplied)
AC voltage: 200 - 500V
DC voltage: 200mV - 500V
DC current: 5A
Resistance: 200Ω - 2000KΩ
Test Lead Length: 570mm
Dimensions: 126 x70 x 29mm
Weight: 128g
Features
Supplied with shrouded testing probes
PVC shockproof jacket
PP3 battery included
Transistor test function
Continuity audible test function
Suare wave testing signal output
Low battery indication
Complies with EN61010 - 1:2010
This set of two battery terminals (Positive & Negative) are compatible with Deep Cycling Leisure Batteries.
Bolt on battery terminals will give you better connection between your solar panel and the battery enhancing the charging performance.
With a choice of 8mm or 10mm diameter posts.
S-S type compatible in-line switch.
This 200mm extension cable is fitted with S-S type connectors on both ends and a switch in the middle.
Ideal for use in solar lighting kits.
Cable Specification
0.75mm max 5A
S-S type compatible in-line switch.
This 200mm extension cable is fitted with S-S type connectors on both ends and a switch in the middle.
Ideal for use in solar lighting kits.
Cable Specification
0.75mm max 5A
Here you can purchase custom size 40mm² Flexible DC cable with pre-attached lugs, ideal for linking multiple batteries together.
Our Flexible DC cable is available in six different cable dimensions (mm²) and cable lengths varying from 200mm to 1200mm with a choice of pre-attached lugs.
This product is cut and crimped in house so if you have a specific requirement, just ask and we would be more than happy to give you a quote.
Heavy Duty 40mm² Flexible Battery Joining Cables custom made with a choice of 8mm or 10mm lugs.
MPPT Solar controllers (Maximum Power Point Tracking) can intelligently regulate the working voltage of solar panels, letting the solar panels always work at Maximum Power Point of V-A curve. Compared with ordinary solar controller, this MPPT controller can increase the efficiency of PV modules by 10% to 30%.
This series of controllers are based on multiphase synchronous rectification technology (MSRT) and advanced MPPT control algorithms, with dual-core processor architecture and common negative design, these features give a high response speed, high reliability, and meets high industrial standards. MSRT can guarantee very high conversion efficiency, which sharply improves the energy efficiency of a solar system; Advanced MPPT control algorithm minimises the maximum power point loss rate and loss time, to ensure the tracking efficiency, corresponding speed as well as a high conversion efficiency under high or low power. In any situation, this controller can rapidly track the maximum power point (MPP) of a PV array to obtain the maximum energy of the panel. The limitation function of the charging power and current, and automatic power reduction function fully ensure the stability when working with oversize PV modules and operating in high temperature environments. The adaptive three-stage charging mode is based on a digital control circuit.
This series of controllers can effectively prolong the life-cycle of batteries, significantly improving the systems performance. The load, utility or generator auto-control relays make it ideal to use with a solar power system and backup generator. All-around electronic protections, including overcharging, over discharging, and PV reverse polarity protection this effectively ensure a safe and reliable solar system. The isolated RS485 interface with standard MODBUS communication protocol and 5V power supply makes it easy for customers to expand the control parameters. Up to 8 controllers can be in linked in parallel for synchronised charging to meet future system expansions and monitoring requirements.
Features
CE certification (LVD EN/IEC62109,EMC EN61000-6-1/3).
High quality & low failure rate components of ST and Infineon to ensure the product’s life.
Advanced MPPT technology & ultra-fast tracking speed, with tracking efficiency no less than 99.5% .
Maximum DC/DC transfer efficiency is as high as 98.6%, full load efficiency is up to 98%.
Advanced MPPT control algorithm will minimise the MPP loss rate and loss time.
The accuracy of the recognition and tracking at the highest point of multiple-peaks MPP.
The wider range of MPP operating voltage.
Auto control system to limit the charging power & current go over the rated value.
Support 4 charging options: Sealed, Gel, Flooded and User.
Battery temperature compensation function.
Real-time energy recording and statistical function.
Automatic over-temperature power reduction function.
Hundred percent full load operation in working environment temperature range within charging & discharging.
Support up to 8 units in parallel to expand system.
Load relay control external load switch signal to realise diversified load work modes.
The first and the second disconnection of load control, contain two relay’s contact.
Auto-control of utility and generator relay design.
Utility or generator auto-control relays make it easy to compose the hybrid power system.
The remote temperature and the voltage sensor design will collect accurate data of battery temperature and voltage.
Isolated RS485 with 5VDC/200mA to protect output for no power devices with MODBUS protocol.
To monitor or set the parameters by using the phone Apps or PC software.
Specifications
Nominal System Voltage: 12/24/36/48VDC or Auto
Battery Input Voltage Range: 8V～68V
Battery Type: Sealed(Default)/Gel/Flooded/User
Max Rated Charging Current: 100 amps
Max Rated Charge Power: 1250W/12V - 2500W/24V - 3750W/36V - 5000W/48V
Max. PV Array Power: 1875W/12V - 3750W/24V - 5625W/36V - 7500W/48V
Max Input Voltage: 150Vdc
Max. conversion efficiency: 98.6%
Full load efficiency: 98%
Tracking efficiency: ≥99.5%
Self Consumption: 98mA/12V;60mA/24V;50mA/36V;46mA/48V
Grounding: Common negative grounding
Relay: Rated Value:5A/30VDC; Max. Value:0.5A/60VDC
Ambient temperature range: -25℃～+60℃ (Derate above 45℃)
Enclosure: IP20
MPPT Solar controllers (Maximum Power Point Tracking) can intelligently regulate the working voltage of solar panels, letting the solar panels always work at Maximum Power Point of V-A curve. Compared with ordinary solar controller, this MPPT controller can increase the efficiency of PV modules by 10% to 30%.
This series of controllers are based on multiphase synchronous rectification technology (MSRT) and advanced MPPT control algorithms, with dual-core processor architecture and common negative design, these features give a high response speed, high reliability, and meets high industrial standards. MSRT can guarantee very high conversion efficiency, which sharply improves the energy efficiency of a solar system; Advanced MPPT control algorithm minimises the maximum power point loss rate and loss time, to ensure the tracking efficiency, corresponding speed as well as a high conversion efficiency under high or low power. In any situation, this controller can rapidly track the maximum power point (MPP) of a PV array to obtain the maximum energy of the panel. The limitation function of the charging power and current, and automatic power reduction function fully ensure the stability when working with oversize PV modules and operating in high temperature environments. The adaptive three-stage charging mode is based on a digital control circuit.
This series of controllers can effectively prolong the life-cycle of batteries, significantly improving the systems performance. The load, utility or generator auto-control relays make it ideal to use with a solar power system and backup generator. All-around electronic protections, including overcharging, over discharging, and PV reverse polarity protection this effectively ensure a safe and reliable solar system. The isolated RS485 interface with standard MODBUS communication protocol and 5V power supply makes it easy for customers to expand the control parameters. Up to 8 controllers can be in linked in parallel for synchronised charging to meet future system expansions and monitoring requirements.
Features
CE certification (LVD EN/IEC62109,EMC EN61000-6-1/3).
High quality & low failure rate components of ST and Infineon to ensure the product’s life.
Advanced MPPT technology & ultra-fast tracking speed, with tracking efficiency no less than 99.5%.
Maximum DC/DC transfer efficiency is as high as 98.6%, full load efficiency is up to 98%.
Advanced MPPT control algorithm will minimise the MPP loss rate and loss time.
The accuracy of the recognition and tracking at the highest point of multiple-peaks MPP.
The wider range of MPP operating voltage.
Auto control system to limit the charging power & current go over the rated value.
Support 4 charging options: Sealed, Gel, Flooded and User.
Battery temperature compensation function.
Real-time energy recording and statistical function.
Automatic over-temperature power reduction function.
Hundred percent full load operation in working environment temperature range within charging & discharging.
Support up to 8 units in parallel to expand system.
Load relay control external load switch signal to realise diversified load work modes.
The first and the second disconnection of load control, contain two relay’s contact.
Auto-control of utility and generator relay design.
Utility or generator auto-control relays make it easy to compose the hybrid power system.
The remote temperature and the voltage sensor design will collect accurate data of battery temperature and voltage.
Isolated RS485 with 5VDC/200mA to protect output for no power devices with MODBUS protocol.
To monitor or set the parameters by using the phone Apps or PC software.
Specifications
Nominal System Voltage: 12/24/36/48VDC or Auto
Battery Input Voltage Range: 8V～68V
Battery Type: Sealed(Default)/Gel/Flooded/User
Max Rated Charging Current: 60 amps
Max Rated Charge Power: 750W/12V - 1500W/24V - 2250W/36V - 3000W/48V
Max. PV Array Power: 1125W/12V - 2250W/24V - 3375W/36V - 4500W/48V
Max Input Voltage: 150Vdc
Max. conversion efficiency: 98.6%
Full load efficiency: 98%
Tracking efficiency: ≥99.5%
Self Consumption: 98mA/12V;60mA/24V;50mA/36V;46mA/48V
Grounding: Common negative grounding
Relay: Rated Value:5A/30VDC; Max. Value:0.5A/60VDC
Ambient temperature range: -25℃～+60℃ (Derate above 45℃)
Enclosure: IP20
Dimensions: 340 × 236 ×119 mm
