sunshineThe Sunshine Solar panels are ideal for keeping 12V batteries topped up. Solar panels are suitable for a wide range of applications however the most common uses for our 110-watt solar panel include supplementing the leisure battery power in caravans, motorhomes, and boats. With a Sunshine 110W solar panel, you could expect to generate around 31 amps per day when used in conjunction with a PWM solar charge controller and around 37 amps per day with an MPPT solar controller during the summer months. Multiple panels can be connected to acquire higher power if needed.  Specifications Maximum Power (Pmax): 110W Maximum Power Current (Ipm): 5.56A Maximum Power Voltage (Vpm): 18.0V Short Circuit Current (Isc): 5.81A Open Circuit Voltage (Voc): 22.50V Nominal Operating Cell Temp. (NOCT): -45 to 80°C Maximum System Voltage: DC1000V Maximum Series Fuse: 9A Size: 664 x 1006 x 35mm Weight: 6.87kg Features 900mm of 4mm single-core insulated cable, fitted with MC Type 4 connectors High-Performance Crystalline Cells Factory-fitted aluminum frame with pre-drilled mounting holes Multiple pieces can be connected to acquire higher power Suitable for charging all types of 12-volt batteries Fitted with bypass diodes to minimize the effect of shading Completely weatherproof Guaranteed Performance 5 Years Manufacturers Warranty 10 Years Warranty 90% Power Output 20 Years Warranty 80% Power Output Suitable Solar Charge Controllers PWM Solar Controller 10A - 12/24V Dual Battery Controller 10A - 12/24V MPPT Solar Controller 10A - 12V/24V (10% - 30% more power generation) Dual MPPT Solar Controller 10A - 12V/24V (10% - 30% more power generation) For the best performance, we would recommend 4mm single core cable is used the same as the existing cable already attached to the solar panel junction box. The most efficient method of extending the existing cable is by using a 4mm single-core cable fitted with a pair of compatible MC Type 4 Solar Connectors. Please view this Document for Info

Read more less

Sunshine 100W solar panel you could expect to generate around 29 amps per day when used in conjunction with a PWM solar charge controller and around 33 amps per day with an MPPT solar controller during the summer months. Multiple panels can be connected to acquire higher power if needed.  DATA SHEET Specifications Maximum Power (Pmax): 100W Maximum Power Current (Ipm): 5.62A Maximum Power Voltage (Vpm): 17.8V Short Circuit Current (Isc): 6.07A Open Circuit Voltage (Voc): 21.30V Nominal Operating Cell Temp. (NOCT): -45 to 80°C Maximum System Voltage: DC1000V Maximum Series Fuse: 9A Size: 510 x 1000 x 35mm Weight: 7.3kg Features 900mm of 4mm single-core insulated cable, fitted with MC Type 4 connectors High Performance Monocrystalline Cells Factory fitted aluminium frame with pre-drilled mounting holes Multiple pieces can be connected to acquire higher power Suitable for charging all types of 12 volt batteries Fitted with bypass diodes to minimise the effect of shading Completely weatherproof Guaranteed Performance 5 Years Manufacturers Warranty 10 Years Warranty 90% Power Output 20 Years Warranty 80% Power Output Suitable Solar Charge Controllers PWM Solar Controller 10A - 12/24V  Dual Battery Controller 10A - 12/24V MPPT Solar Controller 10A - 12V/24V (10% - 30% more power generation) Dual MPPT Solar Controller 10A - 12V/24V (10% - 30% more power generation) Please Note: If you are connecting multiple panels together you may need a bigger solar controller if you are unsure which you require or have any other questions please call 07407221667 For the best performance we would recommend 4mm single core cable is used the same as the existing cable already attached to the solar panel junction box. The most efficient method of extending the existing cable is by using 4mm single-core cable fitted with a pair of compatible MC Type 4 Solar Connectors.   PRODUCT CODE: SSP100SS

Read more less

Sunshine Solar 190w 12vMono Our 190W solar panel is the most powerful of the Sunshine Solar range for 12V battery charging if you are looking for faster power generation this solar module will deliver. The high wattage output combined with high-efficiency monocrystalline cells makes this solar panel particularly interesting for motorhome uses, static caravans, mobile homes, and live-aboard boats where larger power requirements are generally required. With a Sunshine 190W solar panel you could expect to generate around 63 amps per day with an MPPT solar controller during the summer months. Multiple panels can be connected to acquire higher power if needed. Specifications High Efficiency Monocrystalline Cells Maximum Power (Pmax): 190W Maximum Power Current (Ipm): 9.80A Maximum Power Voltage (Vpm): 19.4V Short Circuit Current (Isc): 10.28A Open Circuit Voltage (Voc): 22.7V Nominal Operating Cell Temp. (NOCT): -45 to 80°C Maximum System Voltage: DC1000V Size: 1450mm x 680mm x 35mm Weight: 9.0kg Features 900mm of 4mm single-core cable fitted with MC Type 4 Connectors High Performance Monocrystalline Cells Factory fitted aluminium frame with pre-drilled mounting holes Multiple pieces can be connected to acquire higher power Suitable for charging all types of 12 volt batteries Fitted with bypass diodes to minimise the effect of shading Completely weatherproof Guaranteed Performance 5 Years Manufacturers Warranty 10 Years Warranty 90% Power Output 20 Years Warranty 80% Power Output Suitable Solar Charge Controllers PWM Solar Controller 20A - 12/24V PWM Dual Battery Controller 20A - 12/24V MPPT Solar Controller 20A - 12V/24V (10% - 30% more power generation) MPPT Dual Solar Controller 20A - 12V/24V (10% - 30% more power generation) Please view the link below for more info. Sunshine Solar SRG190

Read more less

This 80W Sunshine Solar Power Caravan & Motorhome Kit offers outstanding performance and great value for money. With this 80 Watt solar power kit, you could expect to generate around 22 amps per day during the summer months supplementing the 12V leisure battery power in caravans, motorhomes, boats, etc. 1 X 80W Polycrystalline Solar Panel 1 X 6M Extension Cables & Connectors 1 X Sunshine 4 Plastic Corner Mounts 1 X ABS Waterproof Cable Entry Cover 1 X Charge Controller Selection Description  This Sunshine Solar Flexible Caravan & Motorhome Kit includes a choice of either a single battery charge controller for one battery bank typically used in caravan solar set-ups or a dual battery controller for optimized battery charging of two battery banks useful for those of you wishing to keep both starter and leisure batteries charged commonly used in motorhome solar set-ups. Monitoring of the system can be made easy with the optional remote meter or via Apple & Android smartphones, tablets, MacBooks, and other devices, using the optional eBox-Bluetooth Adapter. Please note: eBox-Bluetooth Adapter is only compatible with the following Solar Charge Controllers:   Single Battery Controller MPPT Single Battery Controller MPPT Dual Battery Controller   NOT the Dual Battery Controller If you are a competent DIYer this kit has everything you need for a professional-looking finish. If you require the services of an installer please contact our Customer Services at 01508 488188.Solar Panel Specifications High-Efficiency Monocrystalline Cells Maximum Power (Pmax): 60W Maximum Power Current (Ipm): 3.48A Maximum Power Voltage (Vmp): 17.2V Short Circuit Current (Isc): 3.57A Open Circuit Voltage (Voc): 21.5V Nominal Operating Cell Temp. (NOCT): -45 to 80°C Maximum System Voltage: DC1000V Size: 1060 x 460 x 35mm Weight: 6.1kg Kit Performance - Summertime Standard Controller: 17Ah per day - (10-30% more with MPPT Controller) Solar Performance Guarantee 5 Years Manufacturers Warranty 10 Years Warranty 90% Power Output 20 Years Warranty 80% Power Output Important note: The solar panel needs a flat area of 1180mm x 580mm these dimensions include the corner mounts supplied with the kit.  For More Info Please Click PDF For More Info On Installations And Maintenance.

Read more less

This 60W Sunshine Solar Power Caravan & Motorhome Kit offers outstanding performance and great value for money. With this 60 Watt solar power kit, you could expect to generate around 17 amps per day during the summer months supplementing the 12V leisure battery power in caravans, motorhomes, boats, etc. 1 X Sunshine Solar Panels 60W 12V Monocrystalline 1 X 6M Extension Cables & Connectors 1 X Sunshine 4 Plastic Corner Mounts 1 X ABS Waterproof Cable Entry Cover Description  This Sunshine Solar Flexible Caravan & Motorhome Kit includes a choice of either a single battery charge controller for one battery bank typically used in caravan solar set-ups or a dual battery controller for optimized battery charging of two battery banks useful for those of you wishing to keep both starter and leisure batteries charged commonly used in motorhome solar set-ups. Monitoring of the system can be made easy with the optional remote meter or via Apple & Android smartphones, tablets, MacBooks, and other devices, using the optional eBox-Bluetooth Adapter. Please note: eBox-Bluetooth Adapter is only compatible with the following Solar Charge Controllers:   Single Battery Controller MPPT Single Battery Controller MPPT Dual Battery Controller   NOT the Dual Battery Controller If you are a competent DIYer this kit has everything you need for a professional-looking finish. If you require the services of an installer please contact our Customer Services at 01508 488188.Solar Panel Specifications High-Efficiency Monocrystalline Cells Maximum Power (Pmax): 60W Maximum Power Current (Ipm): 3.48A Maximum Power Voltage (Vmp): 17.2V Short Circuit Current (Isc): 3.57A Open Circuit Voltage (Voc): 21.5V Nominal Operating Cell Temp. (NOCT): -45 to 80°C Maximum System Voltage: DC1000V Size: 1060 x 460 x 35mm Weight: 6.1kg Kit Performance - Summertime Standard Controller: 17Ah per day - (10-30% more with MPPT Controller) Solar Performance Guarantee 5 Years Manufacturers Warranty 10 Years Warranty 90% Power Output 20 Years Warranty 80% Power Output Important note: The solar panel needs a flat area of 1180mm x 580mm these dimensions include the corner mounts supplied with the kit.  For More Info Please Click PDF For More Info On Installations And Maintenance.

Read more less

This 70W Sunshine Flexible Solar Power Caravan & Motorhome Kit offers outstanding performance and great value for money. With this 70 Watt solar power kit you could expect to generate around 19 amps per day during the summer months supplementing the 12V leisure battery power in caravans, motorhomes, boats etc. Description This Sunshine Solar Flexible Caravan & Motorhome Kit includes a choice of either a single battery charge controller for one battery bank typically used in caravan solar set-ups or a dual battery controller for optimised battery charging of two battery banks useful for those of you wishing to keep both starter and leisure batteries charged commonly used in motorhome solar set-ups. The Sunshine Flexible Solar range benefit from being thin, light and when fitted to the roof of a caravan or motorhome very aerodynamic. Light weight design combined with high efficiency cells and 3° solar panel flexibility for fitting on slightly curved surfaces our flexible solar range are perfect for caravans, motorhomes and campers. Monitoring of the system can be made easy with the optional remote meter or via Apple & Android smartphones, tablets, MacBook's and other devices, using the optional Bluetooth Adapter. Please note: The Bluetooth Adapter is only compatible with the MPPT Single and Dual Controller Upgrades. Kit Performance - Summertime Standard Controller: 19Ah per day - (10-30% more with MPPT Controller) If you are a competent DIYer this kit has everything you need for a professional looking finish. If you require the services of an installer please contact our Customer Services on 01508 488188.

Read more less

This 840W Sunshine Solar Power Narrowboat Kit offers outstanding performance and great value for money. With this 840 Watt solar power kit you could expect to generate around 280 amps per day (12V Battery System) or 140 amps per day (24V Battery System) during the summer months supplementing the leisure battery power onboard. Whether you are on a liveaboard, day cruising or on the high seas you can rely on Sunshine Solar Panels to keep your batteries in a healthy condition at all times. Solar Panel Specifications Peimar panels offer the quality of one of the few European brands, high efficiency, pleasant design and one of the best warranty on the market. You can find them fitted all over the world making the customers highly satisfied.  The 108 cells Half Cut module combines the high production efficiency of the half cell technology with an excellent quality / price ratio. The half-cell configuration improves the electrical distribution inside the panel to increase the yield of the product. For these reasons, the Half Cell Line is suitable not only for industrial installations but also for residential and commercial installations.  10 years of presence in the market makes Peimar one of the leading European solar companies, offering experience, R&D and technical support. Based in Italy, close to Milan in the most important industrial regions of the country the company motto is: "Our energy for a better future".  Discover what happens when innovation meets technology. Solar Panel Specifications Power Class: 420W Maximum Power Current: (Ipm): 13.17A Maximum Power Voltage: (Vpm): 31.89V Short Circuit Current (Isc): 13.9A Power Output Tolerance (Pmax): 0/+5 Open Circuit Voltage (Voc): 37.87V Nominal Operating Cell Temp. (NOCT): -40 to +85°C Maximum System Voltage: 1500V DC Cells: 108 M10 Half Cells PERC Frame Colour: Black Module Efficiency (%): 22.51 Connector Type: MC4 or compatible connector Length (mm): 1722 Width (mm): 1134 Thickness (mm): 30 Product Weight (Kg): 21.5 Guaranteed Performance 30 Year Linear Power Warranty 25 Year Product Warranty Engineered in Italy   Data Sheet

Read more less

This 35W Sunshine Flexible Solar Power Caravan & Motorhome Kit offers outstanding performance and great value for money. With this 35 Watt solar power kit you could expect to generate around 9.7 amps per day during the summer months supplementing the 12V leisure battery power in caravans, motorhomes, boats etc.  Description  This Sunshine Solar Flexible Caravan & Motorhome Kit includes a choice of either a single battery charge controller for one battery bank typically used in caravan solar set-ups or a dual battery controller for optimised battery charging of two battery banks useful for those of you wishing to keep both starter and leisure batteries charged commonly used in motorhome solar set-ups. The Sunshine Flexible Solar range benefit from being thin, light and when fitted to the roof of a caravan or motorhome very aerodynamic. Light weight design combined with high efficiency cells and a 3° solar panel flexibility for fitting on slightly curved surfaces our flexible solar range are perfect for caravans, motorhomes and campers. Monitoring of the system can be made easy with the optional remote meter or via Apple & Android smartphones, tablets, macbooks and other devices, using the optional eBox-Bluetooth Adapter. Please note: eBox-Bluetooth Adapter is only compatible with the following Solar Charge Controllers:   Single Battery Controller MPPT Single Battery Controller MPPT Dual Battery Controller    NOT the Dual Battery Controller If you are a competent DIYer this kit has everything you need for a professional looking finish. If you require the services of an installer please contact our Customer Services on 01508 488188.  Solar Panel Specifications Maximum Power (Pmax): 20W Maximum Power Current (Ipm): 1.11A Maximum Power Voltage (Vpm): 18V Short Circuit Current (Isc): 1.21A Open Circuit Voltage (Voc): 21.6V Nominal Operating Cell Temp. (NOCT): -45 to 80°C Maximum System Voltage: DC600V Maximum Series Fuse: 10A Size: 420 x 365 x 4mm Weight: 700g One Year Manufacturers Warranty Contents With Unit 1 X 35W 12V Sunshine Solar Flexible ETFE Range 1 X 6M Extension Cables & Connectors 1 X Pair of MC Type 4 Solar Connectors 1 X ABS Waterproof Cable Entry Cover 1 X Charge Controller Selection Kit Performance - Summertime Standard Controller: 5.5Ah per day - (10-30% more with MPPT Controller)  For more info please see in the docs below Doc1 Doc2 Doc3

Read more less

This 420W Sunshine Solar Power Caravan & Motorhome Kit offers outstanding performance and great value for money. With this 420 Watt solar power kit you could expect to generate around 140 amps per day during the summer months supplementing the 12V leisure battery power in caravans, motorhomes, boats etc. Peimar panels offer the quality of one of the few European brands, high efficiency, pleasant design and one of the best warranty on the market. You can find them fitted all over the world making the customers highly satisfied.  The 108 cells Half Cut module combines the high production efficiency of the half cell technology with an excellent quality / price ratio. The half-cell configuration improves the electrical distribution inside the panel to increase the yield of the product. For these reasons, the Half Cell Line is suitable not only for industrial installations but also for residential and commercial installations.  10 years of presence in the market makes Peimar one of the leading European solar companies, offering experience, R&D and technical support. Based in Italy, close to Milan in the most important industrial regions of the country the company motto is: "Our energy for a better future".  Discover what happens when innovation meets technology. Solar Panel Specifications Power Class: 420W Maximum Power Current: (Ipm): 13.17A Maximum Power Voltage: (Vpm): 31.89V Short Circuit Current (Isc): 13.9A Power Output Tolerance (Pmax): 0/+5 Open Circuit Voltage (Voc): 37.87V Nominal Operating Cell Temp. (NOCT): -40 to +85°C Maximum System Voltage: 1500V DC Cells: 108 M10 Half Cells PERC Frame Colour: Black Module Efficiency (%): 22.51 Connector Type: MC4 or compatible connector Length (mm): 1722 Width (mm): 1134 Thickness (mm): 30 Product Weight (Kg): 21.5 Guaranteed Performance 30 Year Linear Power Warranty 25 Year Product Warranty Engineered in Italy

Read more less

This 50W Sunshine Flexible Solar Power Caravan & Motorhome Kit offers outstanding performance and great value for money. With this 50 Watt solar power kit you could expect to generate around 14 amps per day during the summer months supplementing the 12V leisure battery power in caravans, motorhomes, boats etc. etc.  Description  This Sunshine Solar Flexible Caravan & Motorhome Kit includes a choice of either a single battery charge controller for one battery bank typically used in caravan solar set-ups or a dual battery controller for optimised battery charging of two battery banks useful for those of you wishing to keep both starter and leisure batteries charged commonly used in motorhome solar set-ups. The Sunshine Flexible Solar range benefit from being thin, light and when fitted to the roof of a caravan or motorhome very aerodynamic. Light weight design combined with high efficiency cells and 3° solar panel flexibility for fitting on slightly curved surfaces our flexible solar range are perfect for caravans, motorhomes and campers. Monitoring of the system can be made easy with the optional remote meter or via Apple & Android smartphones, tablets, macbooks and other devices, using the optional eBox-Bluetooth Adapter. Please note: eBox-Bluetooth Adapter is only compatible with the following Solar Charge Controllers:   Single Battery Controller MPPT Single Battery Controller MPPT Dual Battery Controller   NOT the Dual Battery Controller If you are a competent DIYer this kit has everything you need for a professional looking finish. If you require the services of an installer please contact our Customer Services on 01508 488188.  Solar Panel Specifications Maximum Power (Pmax): 50W Maximum Power Current (Ipm): 2.78A Maximum Power Voltage (Vpm): 18V Short Circuit Current (Isc): 3.032A Open Circuit Voltage (Voc): 21.6V Nominal Operating Cell Temp. (NOCT): -45 to 80°C Maximum System Voltage: DC600V Maximum Series Fuse: 10A Size: 500 x 665 x 4mm Weight: 1.35 kg One Year Manufacturers Warranty Kit Performance - Summertime Standard Controller: 14Ah per day - (10-30% more with MPPT Controller) Contents With Unit 1 X 50W 12V Sunshine Solar Flexible ETFE Range 1 X 6M Extension Cables & Connectors 1 X Pair of MC Type 4 Solar Connectors 1 X ABS Waterproof Cable Entry Cover 1 X Charge Controller Selection Kit Performance - Summertime: Standard Controller: 5.5Ah per day - (10-30% more with MPPT Controller)  For More Info Please Click PDF For More Info On Installations And Maintenance.

Read more less

With a 320W Sunshine Solar Caravan & Motorhome Kit you could expect to generate around 107 amps per day during the summer months when used in conjunction with the MPPT Single Battery Controller supplied with the kit as standard. MPPT Controllers offer 10%-30% more solar power generation depending on the solar panel specifications, in short the higher the solar panels open circuit voltage (Voc) the harder an MPPT Controller works. To maximise the power generated these two panels should be linked together in series the first panels positive connected to the second panels negative then negative off the first panel and positive off the second solar panel to the solar controller, this will double the voltage generated by the solar panels making the system suitable for 12 volt or 24 volt battery charging. Description The kit includes a choice of either a single battery charge controller for one battery bank typically used in caravan solar set-ups or a dual battery controller for optimised battery charging of two battery banks useful for those of you wishing to keep both starter and leisure batteries charged commonly used in motorhome solar set-ups. Monitoring of the system can be made easy with the optional remote meter or via Apple & Android smartphones, tablets, MacBook's and other devices, using the optional Bluetooth Adapter. Please note: The Bluetooth Adapter is only compatible with the MPPT Single and Dual Controller Upgrades.   Need More Power? ...... Upgrade to an MPPT controller above for 10-30% eXtra Power Solar Panel Specifications High Efficiency Polycrystalline Cells Maximum Power (Pmax): 80W Maximum Power Current (Ipm): 4.49A Maximum Power Voltage (Vpm): 17.8V Short Circuit Current (Isc): 4.85A Open Circuit Voltage (Voc): 21.3V Nominal Operating Cell Temp. (NOCT): -45 to 80°C Maximum System Voltage: DC1000V Size: 665mm x 760mm x 35mm Weight: 5.69kg Kit Performance - Summertime MPPT Controller 107Ah per day. Solar Performance Guarantee 5 Years Manufacturers Warranty 10 Years Warranty 90% Power Output 20 Years Warranty 80% Power Output   Important note: Each solar panel needs a flat area of 790mm x 890mm these dimensions include the corner mounts supplied with the kit.     Data Sheet

Read more less

This 185W Sunshine Solar Power Caravan & Motorhome Kit offers outstanding performance and great value for money. With this 185 Watt solar power kit you could expect to generate around 49 amps per day during the summer months supplementing the 12V leisure battery power in caravans, motorhomes, boats etc. Solar Panel Specifications Brand. Sunshine Solar Product Code. SRG185 Max Power. 185W ± 3% Max Power Voltage. 18.8V Max Power Current. 9.85 Open Circuit Voltage. 22.0V Short Circuit Current. 11.43A Normal Operating Cell Temp. -45 to 85°C Dimensions. 1000 x 960 x 35mm Weight: 8.7kg Guaranteed Performance 5 Years Manufacturers Warranty 10 Years Warranty 90% Power Output 20 Years Warranty 80% Power Output   Data Sheet

Read more less
