Tecma Elegance 2G Lo toilet features a strong polyester-coated wooden seat and soft-closing cover with AIS316L stainless steel and Sugatsune™ dampers. It has the same footprint, outer dimensions and strong macerator technology as previous models, but with an improved design and system.
The macerator and flush hoses are housed within the toilet making installation easy, without the need to accommodate for protruding parts. The hidden side fixings enhance the elegant design and allow for easy installation.
Smooth surfaces make cleaning easier and the improved air inlet incorporated into in the internal hose system improves efficiency across different black water installations.
• Model: Elegance 2G Lo 12V - Freshwater (centralised system) flush
• Control panel: All-in-one with 2 buttons
• Footprint: 390 x 280mm (15.4 x 11.1'')
• H x W x D: 360 x 370 x 430mm (14.2'' x 14.6'' x 16.9'')
• Weight: 19.5kg (42.9lb)
• Water usage: (Per flush) 0.5 - 2.7 Litres (0.1 - 0.7 gal)
• Seat & cover: Polyester-coated wood (soft closing)
• Outlet pump: MAC 11 12V
• Inlet device: Solenoid (optional inlet pump)
Specifications
System
Centralised System (Fresh Water Supply)
Toilet Flush Water
Fresh Water
Toilet Operation
Electric
Brand
Tecma
Voltage Description
12V DC
Model
Elegance 2G Lo
Size
Compact Bowl
Height Description
360mm (14.2")
Width
370mm (14.6'')
Depth
430mm (16.9'')
Weight
19.5kg (42.9lb)
Material
Seat & Cover: Wooden Polyester (soft closing)
Colour
White
Primary Construction
Wood
Tecma 2G Silence Plus Hi toilet features a strong polyester-coated wooden seat and soft-closing cover with AIS316L stainless steel and Sugatsune™ dampers. It has the same footprint, outer dimensions and strong macerator technology as previous models, but with an improved design and system.
The macerator and flush hoses are housed within the toilet making installation easy, without the need to accommodate for protruding parts. The hidden side fixings enhance the elegant design and allow for easy installation.
Smooth surfaces make cleaning easier and the improved air inlet incorporated into in the internal hose system improves efficiency across different black water installations.
• Model: Silence Plus 2G Hi 12V - Freshwater (centralised system) flush
• Control panel: All-in-one with 2 buttons
• Footprint: 405 x 280mm (15.9 x 11.1'')
• H x W x D: 460 x 390 x 510mm (18.1'' x 15.4'' x 20.1'')
• Weight: 25.5kg (56.2lb)
• Water usage: (Per flush) 0.5 - 2.7 Litres (0.1 - 0.7 gal)
• Seat & cover: Polyester-coated wood (soft closing)
• Outlet pump: MAC 11 12V
• Inlet device: Solenoid (optional inlet pump)
Specifications
System
Centralised System (Fresh Water Supply)
Brand
Tecma
Voltage Description
12V DC
Model
Silence Plus 2G Hi
Height Description
460mm (18.1'')
Width
390mm (15.4'')
Depth
510mm (20.1'')
Weight
25.5kg (56.2lb)
Material
Seat & Cover: Wooden Polyester (soft closing)
Colour
White
Primary Construction
Wood
The Elegance 2G Hi toilet features a strong polyester-coated wooden seat and soft-closing cover with AIS316L stainless steel and Sugatsune™ dampers. It has the same footprint, outer dimensions and strong macerator technology as previous models, but with an improved design and system.
The macerator and flush hoses are housed within the toilet making installation easy, without the need to accommodate for protruding parts. The hidden side fixings enhance the elegant design and allow for easy installation.
Smooth surfaces make cleaning easier and the improved air inlet incorporated into in the internal hose system improves efficiency across different black water installations.
• Model: Elegance 2G Hi 24V - Freshwater (centralised system) flush
• Control panel: All-in-one with 2 buttons
• Footprint: 390 x 280mm (15.4 x 11.1'')
• H x W x D: 460 x 370 x 430mm (18.1'' x 14.6'' x 16.9'')
• Weight: 22.5kg (49.6lb)
• Water usage: (Per flush) 0.5 - 2.7 Litres (0.1 - 0.7 gal)
• Seat & cover: Polyester-coated wood (soft closing)
• Outlet pump: MAC 11 24V
• Inlet device: Solenoid (optional inlet pump)
Specifications
System
Centralised System (Fresh Water Supply)
Toilet Flush Water
Fresh Water
Toilet Operation
Electric
Brand
Tecma
Voltage Description
24V DC
Model
Elegance 2G Hi
Size
Compact Bowl
Height Description
460mm (18.1'')
Width
370mm (14.6'')
Depth
430mm (16.9'')
Weight
22.5kg (49.6lb)
Material
Seat & Cover: Wooden Polyester (soft closing)
Colour
White
Primary Construction
Wood
Tecma Elegance 2G Hi toilet features a strong polyester-coated wooden seat and soft-closing cover with AIS316L stainless steel and Sugatsune™ dampers. It has the same footprint, outer dimensions and strong macerator technology as previous models, but with an improved design and system.
The macerator and flush hoses are housed within the toilet making installation easy, without the need to accommodate for protruding parts. The hidden side fixings enhance the elegant design and allow for easy installation.
Smooth surfaces make cleaning easier and the improved air inlet incorporated into in the internal hose system improves efficiency across different black water installations.
• Model: Elegance 2G Hi 12V - Freshwater (centralised system) flush
• Control panel: All-in-one with 1 button
• Footprint: 390 x 280mm (15.4 x 11.1'')
• H x W x D: 460 x 370 x 430mm (18.1'' x 14.6'' x 16.9'')
• Weight: 22.5kg (49.6lb)
• Water usage: (Per flush) 0.5 - 2.7 Litres (0.1 - 0.7 gal)
• Seat & cover: Polyester-coated wood (soft closing)
• Outlet pump: MAC 11 12V
• Inlet device: Solenoid (optional inlet pump)
Specifications
System
Centralised System (Fresh Water Supply)
Brand
Tecma
Voltage Description
12V DC
Model
Elegance 2G Hi
Height Description
460mm (18.1'')
Width
370mm (14.6'')
Depth
430mm (16.9'')
Weight
22.5kg (49.6lb)
Material
Seat & Cover: Wooden Polyester (soft closing)
Colour
White
Primary Construction
Wood
Tecma 2G Silence Plus Hi toilet features a strong polyester-coated wooden seat and soft-closing cover with AIS316L stainless steel and Sugatsune™ dampers. It has the same footprint, outer dimensions and strong macerator technology as previous models, but with an improved design and system.
The macerator and flush hoses are housed within the toilet making installation easy, without the need to accommodate for protruding parts. The hidden side fixings enhance the elegant design and allow for easy installation.
Smooth surfaces make cleaning easier and the improved air inlet incorporated into in the internal hose system improves efficiency across different black water installations.
• Model: Silence Plus 2G Hi 24V - Freshwater (centralised system) flush
• Control panel: All-in-one with 2 buttons
• Footprint: 405 x 280mm (15.9 x 11.1'')
• H x W x D: 460 x 390 x 510mm (18.1'' x 15.4'' x 20.1'')
• Weight: 25.5kg (56.2lb)
• Water usage: (Per flush) 0.5 - 2.7 Litres (0.1 - 0.7 gal)
• Seat & cover: Polyester-coated wood (soft closing)
• Outlet pump: MAC 11 24V
• Inlet device: Solenoid (optional inlet pump)
Specifications
System
Centralised System (Fresh Water Supply)
Brand
Tecma
Voltage Description
24V DC
Model
Silence Plus 2G Hi
Height Description
460mm (18.1'')
Width
390mm (15.4'')
Depth
510mm (20.1'')
Weight
25.5kg (56.2lb)
Material
Seat & Cover: Wooden Polyester (soft closing)
Colour
White
Primary Construction
Wood
Tecma toilet seat assembly 236TBFR for Tecma Elegance 2G toilets, 'thermoset' version with soft close hinge system.
Specifications
Brand
Tecma
Application
Tecma Elegance
Thetford Marine Tecma All-in-one SFT 2P control panel PF.P11 with tank monitoring led and water amount trim.
The All-in-one control panel has a controller directly integrated in the wall interface with the common double function before/after use. Flush is activated by two buttons "Before use" and "After Use". Toilet remains empty for navigation. Tank level monitoring led and water amount trim.
Tecma All-in-one SFT 2P control panel is suitable for use with Tecma X-Light, X-Light Short, Privilege, Evolution, Breeze, E-Breeze, Silence Plus 2G, Silence Plus 2G Short, Elegance 2G, Elegance 2G Short, Elegance 2G Cut, Elegance 2G Cut Short, Nano, Compass and Compass Short toilets.
Note: Compatible with Tecma pneumatic and Mirus field effect sensor or with commercial sensor.
Specifications
Brand
Tecma
Voltage Description
12V / 24V DC
Height Description
91.6mm (3.6")
Width
145mm (5.7")
Depth
Above Surface: 9mm (0.4"), Behind Surface: 56mm (2.2")
Cut Out
110mm x 76mm (4.3" x 3")
Application
Tecma X-Light, X-Light Short, Privilege, Evolution, Breeze, E-Breeze, Silence Plus 2G, Silence Plus 2G Short, Elegance 2G, Elegance 2G Short, Elegance 2G Cut, Elegance 2G Cut Short, Nano, Compass, Compass Short
Tecma Elegance 2G Cut Lo toilet is designed to match with the angled back walls and features a strong polyester-coated wooden seat and soft-closing cover with AIS316L stainless steel and Sugatsune™ dampers. It has the same footprint, outer dimensions and strong macerator technology as previous models, but with an improved design and system.
The macerator and flush hoses are housed within the toilet making installation easy, without the need to accommodate for protruding parts. The hidden side fixings enhance the elegant design and allow for easy installation.
Smooth surfaces make cleaning easier and the improved air inlet incorporated into in the internal hose system improves efficiency across different black water installations.
• Model: Elegance 2G Cut Lo 12V - Freshwater (centralised system) flush
• Control panel: All-in-one with 2 buttons
• Footprint: 310 x 280mm (12.2 x 11.1'')
• H x W x D: 360 x 370 x 430mm (14.2'' x 14.6'' x 16.9'')
• Weight: 19kg (41.8lb)
• Water usage: (Per flush) 0.5 - 2.7 Litres (0.1 - 0.7 gal)
• Seat & cover: Polyester-coated wood (soft closing)
• Outlet pump: MAC 11 12V
• Inlet device: Solenoid (optional inlet pump)
Specifications
System
Centralised System (Fresh Water Supply)
Toilet Flush Water
Fresh Water
Toilet Operation
Electric
Brand
Tecma
Voltage Description
12V DC
Model
Elegance 2G Cut Lo
Size
Compact Bowl
Height Description
360mm (14.2")
Width
370mm (14.6'')
Depth
430mm (16.9'')
Weight
19kg (41.8lb)
Material
Seat & Cover: Wooden Polyester (soft closing)
Colour
White
Primary Construction
Wood
Tecma macerator front cover PF.P39 is suitable for Tecma PF.P01A and PF.P01B waste macerator pumps used in Tecma Design and Flexi toilet ranges.
Specifications
Brand
Tecma
LPS II Lithium-Ion Battery Remote Clayton Power
Connection Instructions
Remote Control Guide
Plug and go - You´ve got the power!
Push Button Remote for the 1 and 2 kWh Li-Ion batteries, allowing you to view state of charge, status and active jump start function.
Model No.
LPS II Remote / RL1802
Width
75 mm
Height
50 mm
Depth
15 mm
Connections
6m Cable
