Fiamma Carry Bike

The Fiamma Pro N Carry-Bike is designed for installation on the rear wall of motorhomes fitted with the Fiamma original bracket. The bike carrier can carry two bikes or can be adapted to carry up to four standard bikes (or two e-bikes) with additional parts (available separately). The Pro N can carry a maximum load of 60kg. The telescopic bike carrier has an adjustable upper structure for better stability. The rounded tube structure is easily adjustable from 80 to 150cm in height to fit different installation requirements. It is supplied with the bottom support bar fixing system. The Fiamma Pro N bike carrier is supplied with: - Bike-Block Pro 1 (bike fixing system) - Bike-Block Pro 3 (bike fixing system) - Security Strip - 2 x Rail Plus (bike rails) - Brackets - Vertical wheelbase: 80-150cm - Horizontal wheelbase (distance between brackets): 60cm - Distance between bike rails: 15cm The carrier can be adapted to carry up to four bikes with the addition of Bike-Block Pro 2 and 4, and two additional Rail Plus rails. This bike carrier can also be installed on the rear walls of caravans, contact our customer service team for advice. Dimensions: 128 x 69 x 80cm (with rail support base in standard open position and in models with minimum adjustable vertical wheelbase). Key Features Restyled 2023 model 6060 aluminium tubes with oval section Height-adjustable frame Carries 2 bikes as supplied or up to 4 standard bikes (or 2 ebikes) with added parts Telescopic rail support Easy Position for the installation of offset rails Bull Shock Absorber for absorbing shocks and vibrations Bike-Block Pro scratch-proof bike locks Sturdy rails with reinforced base delivered with Quick-Safe straps Rack Holder safety carrier lock Support Bar Kit: lower fixings with bar for easy installation Quick Lock for quick and safe locking of the wheel to the rail Dimensions 128 x 69 x 80cm Replaces Fiamma 02094-09V (Nova 12112) Brand Fiamma Height Description 1300mm Width 150mm Depth 560mm Weight 10.2kg Colour Aluminium Maximum Load Description 60kg Application Motorhomes Position Rear Wall Capacity Description 2 Bikes as standard (Maximum 4 Bikes) Supplied With Bike Block Pro 1, Bike Block Pro 3, Security Strip, 2 x Rail Plus, Brackets Optional Extras Bike Block Pro 2, Bike Block Pro 4, 2 x Rail Plus Country of Origin Italy

Read more less

Fiamma Carry-Bike DJ designed for installation on all DJ Series van conversions with rear double door (using vehicle specific fixing bars supplied separately). This bike rack carries two standard bikes. Dedicated fixing bars for each type of vehicle: - Kit Bars DJ Ducato ≥ 06 (08754-01A / 08754-01-) - Kit Bars DJ Sprinter ≥ 06 / Crafter ≥ 06 ≤ 16 (08754-02A / 08754-02-) - Kit Bars DJ Crafter ≥ 17 (08754-03A / 08754-03-) - Kit Bars DJ Transit ≥ 14 (08754-04A / 08754-04-) Supplied with: - 2 x Rail Quick Pro (Bike rails) - Bike-Block Pro 1 (Bike locking system) - Security strip Specs: - Colour: Deep Black - Bikes carried standard: 2 - Bikes carried max.: 2 - Max load: 35kg - E-Bike: No - Weight: 7.8kg - Distance between rails: 23cm - Licence Plate Carrier: Supplied separately Key Features Restyled 2023 model Deep Black finish Carries two standard bikes Designed for use on all DJ Series van conversions with rear double door (using vehicle specific fixing bars supplied separately) Brand Fiamma Width 128cm Depth 55cm Weight 7.8kg Colour Black Maximum Load Description 35kg Application Van Conversions Position Rear Double Door Capacity Description 2 Bikes Supplied With Bike Block Pro 1, 2 x Rail Quick Pro, Security Strip Optional Extras Licence Plate Carrier

Read more less

Fiamma bike carrier designed for installation on Mercedes V Class Vito III series / Mercedes V Class Vito III series Marco Polo ( ≥ 2014 ) vehicles. This bike rack is supplied as standard with two rails for two bikes, but can easily carry up to four bikes (or 2 ebikes) with the additional of Fiamma parts. This model allows the installation of the rail support base in two different positions, one standard and one lower to make it easier to load the bikes. The lower position must be used with the Fiamma License Plate Carrier, which has the license plate holder bar and regulation lights. Supplied with: - 2 x Rail Plus (bike rails) - Fixing bar - Brackets Specs: - Colour: Aluminium - Bikes carried standard: 2 - Bikes carried max.: 4 - Max load: 60kg - E-Bike: Yes - Position: Tailgate - Vertical wheelbase: 95cm - Horizontal wheelbase (distance between brackets): 90cm - Dimensions: 154 x 60 x 9cm (with rail support base in standard open position and in models with minimum adjustable vertical wheelbase) - Weight: 18.3kg - Distance between rails: 15cm - Licence Plate Carrier: Supplied separately Key Features Restyled 2023 model Allows the tailgate to be opened with the bike carrier mounted (without bikes) Dimensions 154 x 60 x 9cm Replaces Fiamma 02094B14A (Nova 13355) Brand Fiamma Height Description 1300mm Width 150mm Depth 560mm Weight 18.3kg Colour Aluminium Maximum Load Description 60kg Application Campervans Position Tailgate Capacity Description 2 Bikes as standard (Maximum 4 Bikes) Supplied With 2 x Rail Plus, Fixing bar, Brackets Optional Extras Licence Plate Carrier Country of Origin Italy

Read more less

Fiamma 08754-02A kit bars for DJ Sprinter >2006 and Crafter >2006 <2016 vans featuring a Deep Black painted aluminium finish. The kit bar is suitable to be used with the Carry-Bike DJ 02096-26A and 02096-26-. Dimensions Vertical Wheelbase: 138cm Brand Fiamma Weight 2.6kg Colour Black

Read more less

Fiamma 08754-01A kit bars for DJ Fiat Ducato ≥ 2006 vans featuring a Deep Black painted aluminium finish. The kit bar is suitable to be used with the Carry-Bike DJ 02096-26A and 02096-26-. Dimensions Vertical Wheelbase: 130cm Brand Fiamma Weight 2.8kg Colour Black

Read more less

Carries 2 bikes as standard but can be adapted to carry up to 4 bikes. • Colour: Blue • Max load: 60kg • Weight: 8.4kg Supplied with, • Quick Pro Rail x 2 • Bike Block Pro 1 and 3 • Straps and Brackets Brand Fiamma Type Bike Carriers Weight 8.4kg Colour Aluminium Maximum Load Description 60kg Approvals N/A Application Motorhomes Capacity Description 2 Bikes as standard (Maximum 4 Bikes) Supplied With Bike Block Pro 1 and 3. Rail Quick Pro x 2. 2M Security Strap. Brackets. Optional Extras Bike Block Pro 2 and 4. Rail Premium S. Bike Cover. Downloads User Manual

Read more less

Similar to the regular UL bike rack the UL-48 has a smaller base tray, projecting only 48cm, meaning it will accept only a maximum of 2 bikes. It is adjustable in height from 80-150cm. Carries a maxium of 2 bikes. • Colour: Black • Max load: 35kg • Weight: 5.4kg Supplied with, • Quick Pro Rail x 2 • Bike Block Pro 2 • Straps and Brackets Brand Fiamma Type Bike Carriers Weight 5.4kg Colour Aluminium Maximum Load Description 35kg Approvals N/A Application Motorhomes Capacity Description 2 Bikes Supplied With Bike Block Pro 2. Rail Quick x 2. 2M Security Strap. Brackets. Optional Extras Bike Block Pro 1. Bike Cover.

Read more less

The Carry Bike UL is a 2 bike carrier that can be added to in order to carry a maximum of 3 bikes. It is adjustable in height from 80-150cm. • Colour: Black • Max load: 55kg • Weight: 5.6kg Supplied with, • Quick Pro Rail x 2 • Bike Block Pro 3 • Straps and Brackets Brand Fiamma Type Bike Carriers Weight 5.6kg Colour Aluminium Maximum Load Description 55kg Approvals TüV Application Motorhomes Capacity Description 2 Bikes as standard (Maximum 3 Bikes) Supplied With Bike Block Pro 3. Rail Quick Pro x 2. 2M Security Strap. Brackets. Optional Extras Bike Block Pro 1. Rail Quick Pro. Bike Cover.

Read more less

Can be installed under the rear window of the motorhome whilst allowing it to open. It is the most compact carrier in the range. Similar spec to Carry Bike Pro C but carries a maximum of 3 bikes. • Colour: Black • Max load: 55kg • Weight: 5.6kg Supplied with, • Quick Pro Rail x 2 • Bike Block Pro 3 • Straps and Brackets Brand Fiamma Type Bike Carriers Weight 5.6kg Colour Aluminium Maximum Load Description 55kg Approvals TüV Application Motorhomes Capacity Description 2 Bikes as standard (Maximum 3 Bikes) Supplied With Bike Block Pro 3. Rail Quick x 2. 2M Security Strap. Brackets. Optional Extras Bike Block Pro 1. Rail Premium S. Bike Cover.

Read more less

The classic XLA Pro and XLA Pro 200 versions are now joined by the new Active model, characterised by its new design and improved functionality it provides greater stability and ease of use. New hooking system for easier access to the storage compartment, maximum manoeuvrability and sturdiness for minimum noise while travelling. Brand Fiamma Type Caravan Bike Carriers Weight 7.5kg Colour Aluminium Maximum Load Description 60kg Approvals N/A Application Caravans Capacity Description 2 Bikes as standard (Maximum 3 Bikes) Supplied With Bike Block Pro S 3. Rail Quick x 2. Optional Extras Bike Block Pro S 2. Rail Premium. Bike Cover. Downloads User Manual

Read more less
