The Battery Balancer equalizes the state of charge of two series connected 12V batteries, or of several parallel strings of series connected batteries.When the charge voltage of a 24V battery system increases to more than 27V, the Battery Balancer will turn on and compare the voltage over the two series connected batteries. The Battery Balancer will draw a current of up to 1A from the battery (or parallel connected batteries) with the highest voltage. The resulting charge current differential will ensure that all batteries will converge to the same state of charge. If needed, several balancers can be paralleled. A 48V battery bank can be balanced with three Battery Balancers.
Features
LED indicators
Green: on (battery voltage > 27,3V) Orange: lower battery leg active (deviation > 0,1V) Orange: upper battery leg active (deviation > 0,1V) Red: alarm (deviation > 0,2V). Remains on until the deviation has reduced to less than 0,14V, or until system voltage drops to less than 26,6V.
Alarm relay
Normally open. The alarm relay closes when the red LED switches on and opens when the red LED switches off
Alarm reset
Two terminals are available to connect a push button. Interconnecting the two terminals resets the relay. The reset condition will remain active until the alarm is over. Thereafter the relay will close again when a new alarm occurs
Even more insight and control with the midpoint monitoring function of the BMV-702 Battery Monitor
The BMV-702 measures the midpoint of a string of cells or batteries. It displays the deviation from the ideal midpoint in volts or percent. Separate deviation percentages can be set to trigger a visual/audible alarm and to close a potential free relay contact for remote alarm purposes.
The 3kW Victron Quattro is a powerful true sine wave inverter, a sophisticated battery charger and a high-speed AC transfer switch in a single compact enclosure. The bigger brother of the Multiplus range, this unit is designed for industrial and commercial systems with multiple AC sources and differential loading, in addition to larger 3-phase systems. The Quattro can take an inputs from a generator and grid supply. It can be used in conjunction with a battery bank and solar PV inverter as an energy storage system. The unit has two AC outputs, one being programmable to only operate when shore/grid power is available; designed for heavy loads such as washing machines etc. Up to 10 Quattro units can operate in parallel to achieve higher power output. Three phase or split phase operation is also possible.
Features
Two AC inputs with integrated transfer switch
The Quattro can be connected to two independent AC sources, for example the public grid and a generator, or two generators. The Quattro will automatically connect to the active source.
Two AC Outputs
The main output has no-break functionality. The Quattro takes over the supply to the connected loads in the event of a grid failure or when shore/generator power is disconnected. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. The second output is live only when AC is available on one of the inputs of the Quattro. Loads that should not discharge the battery, like a water heater for example, can be connected to this output.
Virtually unlimited power thanks to parallel operation
Up to 6 Quattro units can operate in parallel. Six units 48/10000/140, for example, will provide 54kW / 60kVA output power and 840 Amps charging capacity.
Three phase capability
Three units can be configured for three phase output. But that’s not all: up to 6 sets of three units can be parallel connected to provide 162kW / 180kVA inverter power and more than 2500A charging capacity.
PowerControl – Dealing with limited generator, shore side or grid power
The Quattro is a very powerful battery charger. It will therefore draw a lot of current from the generator or shore side supply (16A per 5kVA Quattro at 230VAC). A current limit can be set on each AC input. The Quattro will then take account of other AC loads and use whatever is spare for charging, thus preventing the generator or mains supply from being overloaded.
PowerAssist – Boosting shore or generator power
This feature takes the principle of PowerControl to a further dimension allowing the Quattro to supplement the capacity of the alternative source. Where peak power is so often required only for a limited period, the Quattro will make sure that insufficient mains or generator power is immediately compensated for by power from the battery. When the load reduces, the spare power is used to recharge the battery.
Solar energy: AC power available even during a grid failure
The Quattro can be used in off grid as well as grid connected PV and other alternative energy systems. Loss of mains detection software is available.
System configuring
In case of a stand-alone application, if settings have to be changed, this can be done in a matter of minutes with a DIP switch setting procedure. - Parallel and three phase applications can be configured with VE.Bus Quick Configure and VE.Bus System Configuration software. - Off grid, grid interactive and self-consumption applications, involving grid-tie inverters and/or MPPT Solar Chargers can be configured with Assistants (dedicated software for specific applications).
On-site Monitoring and control S
Several options are available: Battery Monitor, Multi Control Panel, V.E.Net Blue Power panel, Colour Control panel, smartphone or tablet (Bluetooth Smart), laptop or computer (USB or RS232).
Remote Monitoring and control
Victron Ethernet Remote, Victron Global Remote and the Color Control Panel. Data can be stored and displayed on our VRM (Victron Remote Management) website, free of charge.
Remote configuring
When connected to the Ethernet, systems with a Color Control panel can be accessed and settings can be changed.
Please download the link for more info>>
An essential travel accessory that is perfectly-sized, thoughtfully organized and easy to use and clean.
Features
Easily access main compartment with wide mouth opening
Organise small items in internal mesh slip pockets
Contain spills in two water-resistant pockets
Easily grab and go with convenient handle
Conveniently hang at your destination by snapping main compartment flap around a towel bar
Technical specifications
Colour
Black
Material
Nylon
Collection
Thule Crossover 2 Collection
Model number
3204043
A multi-purpose, 2-in-1 pouch that can be separated into a travel wallet and an electronics organizer.
Features
2-in-1 design provides flexibility to use the entire organiser or remove the magnetic pouch as needed for day trips
Safeguard your passport, credit cards and personal information in the detachable, RFID blocking zipped pouch
Store credit cards in elastic straps in RFID pouch
Organise currency, electronics and everyday essentials in zipped mesh pocket and slip pockets
Securely transport with external hand strap or stow in another bag
Store pen in dedicated pen loop
Technical specifications
Colour
Black
Material
Nylon
Collection
Thule Crossover 2 Collection
Model number
3204040
A perfectly-sized solution to organizing life's essentials while on the go.
Features
Organise small essentials such as pens, small electronics, toiletries or charging cables
Easily grab and go with oversized loop
Technical specifications
Colour
Black
Material
Nylon
Collection
Thule Crossover 2 Collection
Model number
3204042
The carry case for the IP65 charger is one of those indispensable accessories. It protects your charger from the knocks and bangs of workshop life. It allows tidy storage, too – cables never get tangled …or lost; everything is in one place; and if you use an IP65 charger in your work – it gives a professional appearance. Compartments accommodate the charger, its input/output cables; plus the battery-clamp/eyelet cable options. (Charger and accessories not included)
Dimensions
Height (mm) 295
Width (mm) - 350
Depth (mm) - 105
The 20A Blue Smart IP22 6-stage battery charger with built-in Bluetooth is a professional quality charger featuring microprocessor controlled ‘adaptive’ charging technology. The battery management software monitors the way the battery is used and automatically optimises the charging process to suit the usage pattern, so maintaining your battery in the best possible condition.
This smart, multi-stage charger operates at up to 93% efficiency and generates up to 4x less heat than some other comparable chargers. When the battery is fully charged and has not been used for 24 hours, storage mode kicks in and power consumption drops to less than 0.5W. Cooling is achieved by a near-silent fan and the unit is fully protected against over-temperature, short circuit and reverse polarity.
Built-in Bluetooth allows you to monitor the status of your charger via any Android or Apple device or laptop and all settings of the charger can be configured with the VictronConnect app.
Suitable for all lead acid batteries (particularly leisure or 'deep-cycle' batteries) and Lithium-ion batteries used in caravans, motorhomes, campervans, cars, boats, off-road, industrial and commercial vehicles
Recommended for batteries with a capacity in the range of 75 - 120Ah
Features
6-stage adaptive charging (Test - Bulk - Absorption - Recondition - Float - Storage)
High efficiency and low heat generation
Charges all lead-acid batteries (flooded, AGM, Gel) and Lithium-Ion batteries
NIGHT and LOW setting - reduces to 50% nominal output and no-fan for silent operation Near-silent fan
Over-temperature protection
Short-circuit protection for DC output
Reverse polarity protection for AC input (ATO blade fuse)
Green LED to indicate Power ON
Yellow LED for charge status indication (Bulk-fast blinking / Absorption-slow blinking / Float-solid / Storage-off)
Screw terminals for connection
Can be used as a power supply when no battery is connected
Charger reduces output current at high temp rather than shut-down
Setup, configuration and monitoring by Bluetooth connection
5 year manufacturer's warranty
Specification
Input voltage rating: 180 - 265V AC
Output voltage (Absorption/Float/Storage): 14.2-14.7/13.5-13.8/13.2-13.5 VDC
Max. charge current: 20A
NIGHT or LOW charge current: 10A
No. charging stages: 6 (adaptive)
No. outputs: 1
Minimum battery capacity: 75Ah
'No load' power consumption: 0.5W
Operating temperature: -20ºC to +50ºC (full rated output up to +30ºC, then output reduces)
Cooling method: Fan-assisted
Mains connection: BS1363 UK 3-pin plug on 1.5m cable
Battery connection: Screw clamp terminals for max. 13mm2 cable (note: output cables and connections not included)
Ingress Protection rating: IP22
Body material: Aluminium (blue RAL5012)
Mounting holes: (download Enclosure dimensions below for full details)
Weight: 1.3kg
Overall dimensions: 235 (L) x 108 (W) x 65 (H) mm
For more info please download this link>>Pdf
The Victron Energy Automotive IP65 Battery Charger 6V/12V-1,1A will automatically adapt its charge algorithm to 6V or 12V batteries making it a very versatile trickle charger for small capacity batteries.
DC connector
Depending on the application, clamps, eyelets or a cigarette plug (all included) can be connected to the charger.
Charges 6V and 12V batteries
The charger will automatically adapt its charge algorithm to 6V or 12V batteries Protected against overheating and reverse polarity connection The output current will reduce as temperature increases up to 40°C, but the charger will not fail. Output relay protects against reverse polarity connection.
Protected against overheating and reverse polarity connection
The output current will reduce as temperature increases up to 40°C, but the charger will not fail. Output relay protects against reverse polarity connection.
Eight LED’s for status and mode indication
When connected to the AC supply the STAND-BY LED will turn on. No voltage will be present at the output. After connection to a battery (battery voltage must exceed 2V in case of a 6V battery and 7V in case of a 12V battery), charging is initiated by pressing the MODE button. The state of charge of the battery is indicated by 4 LED’s:
1. Red LED marked 25% flashing: state of charge less than 25%.
2. Red LED marked 25% on, and red LED marked 50% flashing: state of charge less than 50%.
3. Red LED’s on, and yellow LED marked 75% flashing: state of charge less than 75%.
4. Red and yellow LED’s on and green LED marked 100% flashing: battery nearly charged.
5. All charge level LED’s solid on: battery fully charged. Flooded, AGM or GEL batteries. Ambient temperature below 10°C, or batteries requiring a higher charge voltage (OPTIMA spiral cell batteries for example).
In case of reverse polarity connection, the orange LED ! will turn on after pressing the MODE button. If the red LED STANDBY remains on, even after pressing the MODE button, the connection to the battery is interrupted. The charger always starts in STANDBY mode when connected to the AC supply.
A perfectly-sized solution to organizing life's essentials while on the go.
Features
Organise small essentials such as pens, small electronics, toiletries or charging cables
Easily grab and go with oversized loop
Technical specifications
Colour
Black
Material
Nylon
Collection
Thule Crossover 2 Collection
Model number
3204041
Quickly transfer Thule child bike seat between multiple bikes by using an additional quick release bracket.
Features
Perfect solution for families where two people need to transport the child
Includes screws to mount to round or oval seat tubes
Thule One-Key System lock included
Custom fit kit for mounting a Thule roof rack system to vehicles without pre-existing roof rack attachment points, or factory-installed racks.
Features
Fit kit for vehicles without pre-existing roof rack attachment points or factory-installed racks
Comes as a package of four and helps to attach a complete roof rack system to your specific car
Compatible with Thule Evo Clamp and Thule Edge Clamp foot packs
Check the Thule Buyer's Guide to find out which fit kit fits your car
Compatible vehicles
OPEL
Grandland X 5-dr SUV with Normal Roof 2018 - 0
VAUXHALL
Grandland X 5-dr SUV with Normal Roof 2018 - 0
Mitsubishi L200, 4-dr Double Cab, 05-15
Mitsubishi Triton, 4-dr Double Cab 05-15
Custom fit kit for mounting a Thule roof rack system to vehicles without pre-existing roof rack attachment points, or factory-installed racks.
Features
Fit kit for vehicles without pre-existing roof rack attachment points or factory-installed racks
Comes as a package of four and helps to attach a complete roof rack system to your specific car
Compatible with Thule Evo Clamp and Thule Edge Clamp foot packs
Check the Thule Buyer's Guide to find out which fit kit fits your car
Compatible vehicles
MITSUBISHI
L200 4-dr Double Cab (KB4T) with Normal Roof 2005 - 2015Triton 4-dr Double Cab (KB4T) with Normal Roof 2005 - 2015
