YBX3623
Yuasa YBX3623 12V 180Ah 1175A Super Heavy Duty SMF Commercial Vehicle Battery
Capacity at 20-hour Rate (Ah): 180Cold Cranking Performance (Amps) EN1: 1175
Designed for vehicles with standard power demands
For occasional overnight stops where hotel-loads are applied
V4 vibration resistance & are suitable for end of chassis location
E2 Endurance rating – up to 150 cycles (50% DOD)
Fully maintenance free with sealed double lid
End venting for remote exhaust of gases
Low self-discharge rate for extended shelf life
Yuasa YBX Super Heavy Duty batteries feature:
Original equipment (OE) quality, performance & specification
Specially designed & constructed for the rigours of commercial, agricultural & plant vehicle applications
Enhanced safety features including integrated flame arrestor & carrying handles
Case Type
DIN B
Voltage
12V
Capacity at 20-hour Rate (Ah)
180
Cold Cranking Performance (Amps) EN1
1175
Mean Weight with Acid (kg)
45.3
Cell Layout
4
Terminal
T1
State of Charge Indicator
Yes
Water Loss
W3
Charge Retention
C2
Vibration
V4
Endurance
E2
Terminal Type
T1
Length (mm)
511
Width (mm)
222
Height (mm)
215
