This kit upgrades the Vent F Pro into a Turbo Vent. Includes thermostatic control.
Brand
Fiamma
Type
Accessories
Weight
2kg
Approvals
E24 N136
Diameter Description
300mm
Consumption
36 w
Supplied With
Thermostat
Maximum Air Flow
35m³/min
This kit upgrades the Vent F Pro into a Premium vent, complete with touch pad control panel and thermostatic control.
Brand
Fiamma
Type
Accessories
Weight
2kg
Approvals
E24 N136
Diameter Description
300mm
Consumption
36 w
Supplied With
Touch Control. Thermostat
Maximum Air Flow
35m³/min
This kit upgrades the Vent F Pro into a Turbo Vent P3. Does not include thermostatic control.
Brand
Fiamma
Type
Accessories
Voltage Description
N/A
Weight
2kg
Approvals
E24 N136
Diameter Description
300mm
Consumption
36 w
Maximum Air Flow
35m³/min
This 12V vent kit can be added to the Fiamma Rooflight Vent 28 to enhance ventilation throughout the vehicle.
Product Code: 26915
Brand
Fiamma
Type
Accessories
Application
Fiamma Rooflight Vent 28
Country of Origin
Italy
Downloads
User Guide Fiamma Turbo Vent 28 F Kit
A classic roof vent with a 12V DC variable speed motor suitable for motorhomes, caravans and van conversions.
This 40 x 40cm Fiamma model is fitted with an aluminium mosquito net and has a transparent 'crystal' cover letting in as much light as possible.
The aerodynamic design means the vent does not need to be fitted with a spoiler and noise and vibrations are greatly reduced.
A patented rubber seal and high-quality UV resistant materials guarantee a watertight system whilst protecting the vent and vehicle against the elements.
This model is interchangeable with older 40 x 40cm Fiamma roof vent models and with vents from 36 x 36cm to 42 x 42cm, thanks to its reinforced frame.
- Cover: Transparent 'crystal'
- Power consumption: 36W
- Minimum absorption: 0.3A
- Maximum input: 3A
- Maximum air flow: 35 m³/min
Key Features
Variable fan speed
Aerodynamic shape means that a spoiler is not required
Fitted with aluminium mosquito net
Allows constant air circulation
ABE approved
Product Code:27112
Brand
Fiamma
Type
Powered Roof Vent
Size
40cm x 40cm
Weight
4.6kg
Approvals
ABE 19330 E24 10R-030530
Application
Caravans, Motorhomes, Van Conversions
Country of Origin
Italy
Downloads
User Guide Fiamma Rooflight Turbo Vent
A classic roof vent with a 12V DC variable speed motor suitable for motorhomes, caravans and van conversions.
This 40 x 40cm Fiamma model is fitted with an aluminium mosquito net and has a transparent 'crystal' cover letting in as much light as possible.
The aerodynamic design means the vent does not need to be fitted with a spoiler and noise and vibrations are greatly reduced.
A patented rubber seal and high-quality UV resistant materials guarantee a watertight system whilst protecting the vent and vehicle against the elements.
This model is interchangeable with older 40 x 40cm Fiamma roof vent models and with vents from 36 x 36cm to 42 x 42cm, thanks to its reinforced frame.
- Cover: Transparent 'crystal'
- Power consumption: 36W
- Minimum absorption: 0.3A
- Maximum input: 3A
- Maximum air flow: 35 m³/min
Key Features
Variable fan speed
Aerodynamic shape means that a spoiler is not required
Fitted with aluminium mosquito net
Allows constant air circulation
ABE approved
Brand
Fiamma
Type
Powered Roof Vent
Size
40cm x 40cm
Weight
4.6kg
Approvals
ABE 19330 E24 10R-030530
Application
Caravans, Motorhomes, Van Conversions
Country of Origin
Italy
Downloads
User Guide Fiamma Rooflight Turbo Vent
The Fiamma Turbo Vent Premium is a 12V DC motorised roof vent with simple finger touch operation and an electronic interface with signal LEDs.
Suitable for motorhomes, caravans and van conversions, this 40 x 40cm vent has a UV resistant white cover and is fitted with an aluminium mosquito net.
The aerodynamic design means this model does not need to be fitted with a spoiler and noise and vibrations are greatly reduced.
A patented rubber seal and high-quality UV resistant materials guarantee a watertight system whilst protecting the vent and vehicle against the elements.
This model is interchangeable with older 40 x 40cm Fiamma roof vent models and with vents from 36 x 36cm to 42 x 42cm, thanks to its reinforced frame.
Cover: White
Power consumption: 36W
Minimum absorption: 0.3A
Maximum input: 3A
Maximum air flow: 35 m³/min
Key Features
Polar Control thermostat
Touch control unit with LEDs
Variable fan speed
Aerodynamic shape means that a spoiler is not required
Fitted with aluminium mosquito net
Allows constant air circulation
ABE approved
Prod Code:27117
Brand
Fiamma
Type
Powered Roof Vent
Size
40cm x 40cm
Weight
4.6kg
Approvals
ABE 19330 E24 10R-030530
Application
Caravans, Motorhomes, Van Conversions
Country of Origin
Italy
Downloads
User Guide Fiamma Rooflight Turbo Vent Premium
The Fiamma Turbo Vent Premium is a 12V DC motorised roof vent with simple finger touch operation and an electronic interface with signal LEDs.
Suitable for motorhomes, caravans and van conversions, this 40 x 40cm model is fitted with an aluminium mosquito net and has a transparent 'crystal' cover letting in as much light as possible.
The aerodynamic design means the vent does not need to be fitted with a spoiler and noise and vibrations are greatly reduced.
A patented rubber seal and high-quality UV resistant materials guarantee a watertight system whilst protecting the vent and vehicle against the elements.
This model is interchangeable with older 40 x 40cm Fiamma roof vent models and with vents from 36 x 36cm to 42 x 42cm, thanks to its reinforced frame.
Cover: Transparent 'crystal'
Power consumption: 36W
Minimum absorption: 0.3A
Maximum input: 3A
Maximum air flow: 35 m³/min
Key Features
Polar Control thermostat
Touch control unit with LEDs
Variable fan speed
Aerodynamic shape means that a spoiler is not required
Fitted with aluminium mosquito net
Allows constant air circulation
ABE approved
Brand
Fiamma
Type
Powered Roof Vent
Size
40cm x 40cm
Weight
4.6kg
Approvals
ABE 19330 E24 10R-030530
Application
Caravans, Motorhomes, Van Conversions
Country of Origin
Italy
Downloads
User Guide Fiamma Rooflight Turbo Vent Premium
A 28cm x 28cm Fiamma roof vent recommended for small rooms such as bathrooms, showers, or kitchens in motorhomes, caravans, van conversions and campervans.
Discreet in design, this slim framed vent provides permanent ventilation and lets in as much light as possible through its transparent cover. It is supplied with an integrated aluminium mosquito net that can be removed for easy cleaning.
Thanks to the ‘sandwich’ mounting system, this model can be installed without having to drill any additional holes in the roof of the vehicle.
The vent's aerodynamic design means it does not need to be fitted with a spoiler, and noise and vibrations are greatly reduced.
A motorised fan can be added to this rooflight, see Fiamma Turbo-Vent 28 F Kit, product code 26915.
Key Features
Aerodynamic shape means that a spoiler is not required
Quick installation without the need to cut more holes in vehicle roof
Permanent ventilation for constant exchange of air
Simple opening system with handwheel
Removable aluminium mosquito net
Can be motorised with Fiamma Turbo-Vent 28 F Kit
Brand
Fiamma
Type
Roof Vent
Size
28cm x 28cm
Weight
1.8kg
Application
Caravans, Motorhomes, Van Conversions, Campervans
Country of Origin
Italy
Downloads
User Guide Fiamma Rooflight Vent 28 F
