The built-in Cassette Toilet consists of two parts: a permanently installed toilet and a removable waste-holding tank. A clever indicator lets you know when the tank needs to be emptied, and you can access and remove the tank through a small door on the outside of the vehicle. The C263-S is designed to drawn its flushing water from an onboard water tank.
Capacity of waste-holding tank: 17.5 Litres
Main dimensions: Height 488mm x Width 341mm x Depth 603mm
Waste-holding tank on wheels: Yes
Weight: 16.2kg
Bowl material: Ceramic
Flushing system: Electric
Type: Plumbed into water system
Key Features
Highest level of seating comfort on the market
Toilet bowl swivels
Quiet yet powerful flushing system with full bowl coverage
3 year warranty
Easy and convenient emptying
Waste-holding tank indicates when it needs emptying
Waste-holding tank on wheels
Vent button for emptying without splashing
Automatic pressure release vent prevents gas build-up, ensures splash-free tank opening
Built-in rotating spout for emptying
Brand
Thetford
Type
Plumbed In Flush Water Supply
Height Description
468mm, Seating: 479mm
Width
341mm
Depth
603mm
Weight
16.2kg
Material
Ceramic Bowl
Flush System
12V
Position
Landscape
Capacity Description
17.5 Litres
For maximum comfort without losing space, the toilet bowl revolves 180 degrees on the base; simply press down on the seat and the bowl locks into place. The C200 model can be installed as a freestanding unit against any wall with suitable access to the waste tank.
Brand
Thetford
Type
Plumbed In Flush Water Supply
Height Description
468mm, Seating: 479mm
Width
341mm
Depth
603mm
Weight
479mm
Material
Plastic Bowl
Flush System
12V
Position
Landscape
Capacity Description
17.5 Litres
Thetford C402-C left-handed OE light-weight toilet is made from durable plastic and built for comfort. It has a quiet yet powerful flushing system and provides easy and convenient emptying.
PLEASE NOTE: These toilets are not for resale into the retail market, they are specifically intended for vehicle converters and boat builders, and as such do not contain all the parts associated with a retail packaged product.
Features:
Capacity of flush water tank - 15L.
Capacity of waste holding tank - 19.3L.
Central water connection: No.
Flushing System: Electric.
Level indicator for flush water tank: 3 indication levels.
Level indicator for waste holding tank: 3 indication levels.
Removable mechanism for waste holding tank - Yes.
Key Features
Highest level of seating comfort on the market
Lightweight, high-quality, durable plastic
Quiet yet powerful flushing system with full bowl coverage
Easy & convenient emptying
Brand
Thetford
Type
Integrated Flush Water Tank
Height Description
512mm, Seating: 473mm
Width
670mm
Depth
400mm (15-3/4")
Weight
8.8kg
Material
Plastic Bowl
Flush System
Electric
Position
Portrait
Capacity Description
Waste: 19.3L, Water: 15L
Tank With Wheels
Yes
Water Fill Required
No
Thetford C224-CW basic toilet (no passive vent) has a removable waste-holding tank and is made from high-quality durable plastic.
PLEASE NOTE: These toilets are not for resale into the retail market, they are specifically intended for vehicle converters and boat builders, and as such do not contain all the parts associated with a retail packaged product.
Features:
Capacity of flush water tank - 9L
Capacity of waste holding tank - 18L
Central water tank connection: Yes.
Manual flushing system.
Level indicator for waste holding tank: 1 indication level.
Removable mechanism for waste holding tank: No.
Waste holding tank on wheels: Yes
Water fill door needed: Yes
Key Features
Highest level of seating comfort on the market.
Lightweight, high-quality, durable plastic.
Easy and convenient emptying.
Brand
Thetford
Type
Cassette Toilets
Height Description
750mm, Seating: 492mm
Width
417mm
Depth
600mm
Weight
6.8kg
Material
Plastic Bowl
Flush System
Manual
Position
Portrait or Landscape
Capacity Description
Waste: 18L, Water: 9L
Tank With Wheels
Yes
Water Fill Required
No
The BI-POT is an extremely strong Fiamma built portable toilet, available in three different sizes (Small 30, Medium 34 and Large 39). The Fiamma BI-POT is a simple and self-contained fresh water flush system. The system is easy to clean and extremely compact which makes dismantling easy. The Fiamma BI-POT has a strong and sturdy handle for transportation.
Fiamma quality assured backed by each tank being electronically tested to check the seal before packaging. Handy side clips attach the two parts of the system together.
BIPOT 34 Specifications:
Upper Tank 15L
Lower Tank 13L
Weight 4.7KG
Dimensions 43.5cm (D) x 36(W) x 34(H)
Brand
Fiamma
Type
Portable Toilets
Height Description
34cm
Width
36cm
Depth
43.5cm
Weight
4.3kg
Colour
Grey
Capacity Description
Waste: 13L, Water: 15L
Thetford C223-CS basic toilet (no passive vent) has a removable waste-holding tank and is made from high-quality durable plastic.
PLEASE NOTE: These toilets are not for resale into the retail market, they are specifically intended for vehicle converters and boat builders, and as such do not contain all the parts associated with a retail packaged product.
Features:
Capacity of waste holding tank - 18L
Central water tank connection: Yes.
Electric flushing system.
Level indicator for waste holding tank: 1 indication level.
Removable mechanism for waste holding tank: No.
Waste holding tank on wheels: Yes
Water fill door needed: No
Key Features
Highest level of seating comfort on the market.
Lightweight, high-quality, durable plastic.
Quiet yet powerful flushing system with full bowl coverage.
Easy and convenient emptying.
Brand
Thetford
Type
Cassette Toilets
Height Description
534mm, Seating: 492mm
Width
394mm
Depth
580mm
Weight
6.8kg
Material
Plastic Bowl
Flush System
?
Position
Portrait or Landscape
Capacity Description
Waste: 18L
Tank With Wheels
Yes
Water Fill Required
No
Thetford C223-S basic toilet (no passive vent) has a removable waste-holding tank and is made from high-quality durable plastic.
PLEASE NOTE: These toilets are not for resale into the retail market, they are specifically intended for vehicle converters and boat builders, and as such do not contain all the parts associated with a retail packaged product.
Features:
Capacity of waste holding tank - 18L
Central water tank connection: Yes.
Electric flushing system.
Level indicator for waste holding tank: 1 indication level.
Removable mechanism for waste holding tank: No.
Waste holding tank on wheels: Yes
Water fill door needed: No
Key Features
Highest level of seating comfort on the market.
Lightweight, high-quality, durable plastic.
Easy and convenient emptying.
Brand
Thetford
Type
Cassette Toilets
Height Description
495mm, Seating: 492mm
Width
365mm
Depth
580mm
Weight
6.8kg
Material
Plastic Bowl
Flush System
?
Position
Portrait or Landscape
Capacity Description
Waste: 18L
Tank With Wheels
Yes
Water Fill Required
No
Thetford C402-C right-handed OE light-weight toilet is made from durable plastic and built for comfort. It has a quiet yet powerful flushing system and provides easy and convenient emptying.
PLEASE NOTE: These toilets are not for resale into the retail market, they are specifically intended for vehicle converters and boat builders, and as such do not contain all the parts associated with a retail packaged product.
Features:
Capacity of flush water tank - 15L.
Capacity of waste holding tank - 19.3L.
Central water connection: No.
Flushing System: Electric.
Level indicator for flush water tank: 3 indication levels.
Level indicator for waste holding tank: 3 indication levels.
Removable mechanism for waste holding tank - Yes.
Key Features
Highest level of seating comfort on the market
Lightweight, high-quality, durable plastic
Quiet yet powerful flushing system with full bowl coverage
Easy & convenient emptying
Brand
Thetford
Type
Integrated Flush Water Tank
Height Description
512mm, Seating: 473mm
Width
670mm
Depth
400mm (15-3/4")
Weight
8.8kg
Material
Plastic Bowl
Flush System
Electric
Position
Portrait
Capacity Description
Waste: 19.3L, Water: 15L
Tank With Wheels
Yes
Water Fill Required
No
The two handles make it easy to transport the Porta Potti, whilst also making it discrete to carry your tank. The bag has a durable zip and is made of sturdy bag material. The interior of the bag has a gloss finish for easy cleaning. The bag itself is washable in the domestic washing machines (max 40C). This way the bag is ideal for transportation and protection of your portable toilet and you don't need to keep the carton box. The Porta Potti Carry Bag comes in two sizes. One for the bigger range, the Porta Potti x65 series (Porta Potti 165, 365 & 565), and one for the smaller sized portable as the Porta Potti 335, 145 & 345.
Brand
Thetford
Type
Portable Toilet Spares
Colour
Black
The Qube 335 with the hold down kit is a super compact portable toilet which is perfect to use on boats. The toilet is delivered with a special ‘hold down kit’ to attach the toilet to the floor of your boat, wherever you want. One simple action releases the toilet.
Dimensions HxWxD: 313 x 342 x 382mm
Waste Tank Capacity: 10L
Seating Height: 308mm
Flush Water Tank Level Indicator: No
Flushing System: Piston
Flush Water Tank Capacity: 10L
Waste Tank Level Indicator: Yes
Net Weight: 3.3 Kg
Brand
Thetford
Type
Portable Toilets
Height Description
31.3cm, Seating: 30.8cm
Width
342mm
Depth
38.2cm
Weight
3.3kg
Colour
White
Flush System
Piston
Capacity Description
Waste: 11L, Water: 10L
Level Indicator
Waste Tank
Downloads
User Manual
Hold Down Kit Guide
Spare Parts Guide
The Qube 345 is a medium sized portable model with a slightly higher capacity waste holding tank.
Dimensions: Height 330mm x Width 383mm x Depth 427mm
Waste Tank Capacity: 12L
Seating Height: 324mm
Flush Water Tank Level Indicator: No
Flushing System: Piston
Flush Water Tank Capacity: 15L
Waste Tank Level Indicator: Yes
Net Weight: 3.8Kg
Brand
Thetford
Type
Portable Toilets
Height Description
33cm, Seating: 32.4cm
Width
38.3cm
Depth
42.7cm
Weight
3.8kg
Colour
White
Flush System
Piston
Capacity Description
Waste: 12L, Water: 15L
Level Indicator
Waste Tank
Downloads
User Manual
Spare Parts Guide
The Porta Potti 565 is the top of the range; it’s designed for those who seek high quality and innovation.
Features include:
Integrated toilet paper holder
Flush-water level indicator
Covered controls for flush, water fill cap, water level indication
Water fill adaptor
Comfortable seating height (440mm)
Bigger bowl size
User friendly valve handle at side
Waste Tank Capacity: 21Ltr
Flush Water Capacity: 15Ltr
Dimensions: 448mm(h) x 388mm(w) x 450mm(d)
Weight: 5.8Kg
Brand
Thetford
Type
Portable Toilets
Height Description
44.8cm, Seating: 44.3cm
Width
38.8cm
Depth
45cm
Weight
5.3kg
Colour
White
Flush System
Piston
Capacity Description
Waste: 21L, Water: 15L
Level Indicator
Waste & Water Tank
Dwonloads
User Manual
Installation Instructions
Spare Parts List
The Porta Potti 565E is the only model that is equipped with a luxurious electric flushing system. It uses six 1.5 V AA batteries, enough to last for 500 to 700 flushes.
Features include:
Integrated toilet paper holder
Flush-water level indicator
Covered controls for flush, water fill cap, water level indication
Water fill adaptor
Comfortable seating height (440mm)
Bigger bowl size
User friendly valve handle at side
Waste Tank Capacity: 21Ltr
Flush Water Capacity: 15Ltr
Dimensions: 448mm(h) x 388mm(w) x 450mm(d)
Weight: 6Kg
Brand
Thetford
Type
Portable Toilets
Height Description
44.8cm, Seating: 44.3cm
Width
38.8cm
Depth
45cm
Weight
5.3kg
Colour
White
Flush System
Piston
Capacity Description
Waste: 21L, Water: 15L
Level Indicator
Waste & Water Tank
Dwonloads
User Manual
Installation Instructions
Spare Parts List
