Motorhome Heaters, Water Tanks and Plumbing

The Combi 2 E liquid gas heater is a warm air heater with an integrated hot water boiler. The appliance also has heating elements for electrical operation. In heating mode, the heater can be used to heat both the vehicle and water simultaneously. Or if hot water alone is required, the hot water mode can be selected. The lightweight combination heater runs in gas mode for self-sufficient use, in electrical mode for stationary use, and in mixed mode when outside temperatures are low. A 10-litre stainless steel water tank is integrated into the system, which is jointly heated in winter. In summer mode, the user can heat the water independently of the heater. The water then reaches a temperature of 60 degrees in about 20 minutes. With the Truma App, the user can switch their Combi heater on from a smartphone. • Heating Mode In Heating Mode the appliance automatically selects the required operating level according to the temperature difference between the temperature set on the control panel and the current room temperature. If the water container has been filled, the water is automatically heated as well. The water temperature depends on the selected operating mode and the heater output. Energy selection options: Gas mode: In this mode the appliance automatically selects the operating level that is required. Electric mode: In this mode an output of 980 W (3.9 A) or 1960 W (7.8 A) can be manually preselected in accordance with the fuse protection at a campsite. If more output is required (e.g. heating up or low outside temperatures) gas or mixed mode should be selected so that enough heating power is always available. Mixed mode: In this setting 230V electric mode is preferred if the power requirement is only low (e.g. for maintaining the room temperature). The gas burner is not enabled until the power requirement is higher, and is the first to switch off during heat-up operations. • Hot Water Mode (with filled water container only) Gas mode or 230V electric mode is used for hot water preparation. The water temperature can be set to 40 °C / ECO or 60 °C / HOT (ECO, HOT only with control panel Truma CP plus). Gas mode: In this mode the water is heated at the lowest burner setting. Once the water temperature has been reached, the burner switches off. Electric mode: In this setting an output of 980 W (3.9 A) or 1960 W (7.8 A) can be manually selected in accordance with the fuse protection at a campsite. Mixed mode is not possible with the Hot Water Mode setting as the appliance automatically selects electric mode. If the 230V power supply is disconnected or fails, the heater automatically switches over to gas mode. The Truma Combi 2E Boiler and Space Heater Kit contains: Truma Combi 2E LPG gas and 230V electric unit Truma CP Plus digital control panel John Guest water connection kit ZR80 exhaust ducting 1 metre ZRS clip Truma Combi CP Plus cable 6m Side wall cowl in black JST electrical ends Installation and operation manuals Technical Specifications: Truma Combi 2E Dimensions (L x W x H): 510 x 450 x 300 mm Installation dimensions (L x W x H): 540 x 500 x 350mm (plus connections and drain valve) Weight (empty): 15.1kg Heating time (from 15°C to 60°C) (Water only): Approx. 20min. Heating time (from 15°C to 60°C) (Heater & Water): Approx. 80min. Rated thermal output (Electric): 980W / 1960W Rated thermal output (Gas): 1950W maximum Rated thermal output (Electric & Gas Combined): 3900W Fuel consumption (Gas): 130 g/h Water capacity: 10 litres Air flow rate: Max. 287 m3/h Power consumption (at 230V): 3.9A / 7.8A Power consumption (at 12V): Heating up boiler 0.2A up to temporary 5.6A maximum (average approx. 1.1A) Water pressure: 2.8 Bar maximum

Read more less

Truma water heater non-return valve. Ultrastore / Boiler Series 3 (07/93 onwards), Ultrastore Rapid GE, Boat Boiler Series 2 (06/96 to 06/02), Boat Boiler Series 3 (07/02 onwards), Electro boiler (05/04 onwards). (70000-03300) Brand Truma Type Valves

Read more less

Truma water heater cowl cover KBS 3, White. Ultrastore / Boiler Series 3 (From 07/06). (70122-01) Brand Truma Type Flue Cowls

Read more less

Truma water heater cowl cover KBS 3, White. Ultrastore / Boiler Series 3 (From 07/06). (70122-01) Brand Truma Type Flue Cowls

Read more less

The Pundmann camper van 3L water heater is designed to bring creature comfort to camper adventures. Every unit is built to last and individually bench tested to ensure long term performance and safety. The off-grid units are all compact and easy to install for efficient use of small spaces as well as safe and stable. Perfect for campervans, motorhomes, caravans, boats, off grid locations, service vehicles, mountain top cabins, sandy shored beach huts, long distance lorry drivers and even the shed at the end of your garden. These electric water heaters are uniquely compact and narrow so they fit in the wardrobe of VW Campervans such as T4, T5 or T6. Designed to heat up as you travel to your adventure, and fully compatible with solar power for the greenest hot water! Heats your water to 60°C in as little as 50 minutes. Well supported by our team for customer support and technical advice. Underpinned by a 3 year warranty. Key Features Twin immersion heater rods, 12V 180W and 230V 250W fitted with 5A 3-pin plug Insulated 316 stainless steel welded tank with high quality stainless heating rods Designed for safe use up to 2.3bar Supplied & fitted with a 3 bar hot water safety pressure release valve Designed to be compact & straight forward to install Engineered to provide excellent service 3 Year return to base Warranty Brand Pundmann Voltage Description 12V DC & 230V AC Height Description 200mm Width 228mm Length Heater: 217mm, Connections: 85mm Material Insulated 316 stainless steel welded tank with high quality stainless heating rods. Wattage 180W at 12V, 250W at 230V Operating Pressure 2.3 bar Maximum Hose Tail Size 10mm / 3/8" Pressure Rating 3 bar pressure relief valve Amps Description 15A at 12V, 1.04A at 230V Capacity Description 3 Litres Warranty 3 Years Downloads pundmann decloration of conformity pundmann diagrams pundmann faqs pundmann wiring plumbing guidelines

Read more less

The Pundmann off-grid 6L water heater is designed to bring creature comfort to camper van adventures. Every unit is built to last and individually bench tested to ensure long term performance and safety. The water heater units are all compact and easy to install for efficient use of small spaces as well as safe and stable. Perfect for campervans, motorhomes, caravans, boats, off grid locations, service vehicles, mountain top cabins, sandy shored beach huts, long distance lorry drivers and even the shed at the end of your garden. These electric water heaters are uniquely compact and narrow so they fit in the wardrobe of VW Campervans such as T4, T5 or T6. Designed to heat up as you travel to your adventure, and fully compatible with solar power for the greenest hot water! Heats your water to 75°C in as little as 50 minutes. Well supported by our team for customer support and technical advice. Underpinned by a 3 year warranty. Please Note: There is no maximum temperature cut off when coupled with a heater, it is recommended you install a thermostatic blending valve to control the maximum temperature of water to the tap. Key Features Combi tank with air heat exchanger Twin immersion heater rods, 12V 200W and 230V 500W fitted with 5A 3-pin plug Compatible with diesel or gas heaters & works efficiently with 2kw or 4kw heaters Insulated 316 stainless steel welded tank with high quality stainless heating rods Designed for safe use up to 2.3bar Supplied & fitted with a 3 bar hot water safety pressure release valve Designed to be compact & straight forward to install Engineered to provide excellent service 3 Year return to base Warranty Brand Pundmann Voltage Description 12V DC & 230V AC Height Description 200mm Width 228mm Length Heater: 360mm, Connections: 85mm Material Insulated 316 stainless steel welded tank with high quality stainless heating rods. Wattage 200W at 12V, 500W at 230V Operating Pressure 2.3 bar Maximum Hose Tail Size 10mm / 3/8" Pressure Rating 3 bar pressure relief valve Amps Description 16.67A at 12V, 2.08A at 230V Capacity Description 6 Litres Warranty 3 Years Downloads pundmann decloration of conformity pundmann diagrams pundmann faqs pundmann wiring plumbing guidelines

Read more less

The Pundmann off-grid 10L water heater is designed to bring creature comfort to camper van adventures. Every unit is built to last and individually bench tested to ensure long term performance and safety. The water heater units are all compact and easy to install for efficient use of small spaces as well as safe and stable. Perfect for campervans, motorhomes, caravans, boats, off grid locations, service vehicles, mountain top cabins, sandy shored beach huts, long distance lorry drivers and even the shed at the end of your garden. These electric water heaters are uniquely compact and narrow so they fit in the wardrobe of VW Campervans such as T4, T5 or T6. Designed to heat up as you travel to your adventure, and fully compatible with solar power for the greenest hot water! Heats your water to 75°C in as little as 50 minutes. Well supported by our team for customer support and technical advice. Underpinned by a 3 year warranty. Please Note: There is no maximum temperature cut off when coupled with a heater, it is recommended you install a thermostatic blending valve to control the maximum temperature of water to the tap. Key Features Combi tank with air heat exchanger Twin immersion heater rods, 12V 200W and 230V 500W fitted with 5A 3-pin plug Compatible with diesel or gas heaters & works efficiently with 2kw or 4kw heaters Insulated 316 stainless steel welded tank with high quality stainless heating rods Designed for safe use up to 2.3bar Supplied & fitted with a 3 bar hot water safety pressure release valve Designed to be compact & straight forward to install Engineered to provide excellent service 3 Year return to base Warranty Brand Pundmann Voltage Description 12V DC & 230V AC Height Description 200mm Width 228mm Length Heater: 520mm, Connections: 85mm Material Insulated 316 stainless steel welded tank with high quality stainless heating rods. Wattage 200W at 12V, 500W at 230V Operating Pressure 2.3 bar Maximum Hose Tail Size 10mm / 3/8" Pressure Rating 3 bar pressure relief valve Amps Description 16.67A at 12V, 2.08A at 230V Capacity Description 10 Litres Warranty 3 Years Downloads pundmann decloration of conformity pundmann diagrams pundmann faqs pundmann wiring plumbing guidelines

Read more less

The Truma Ultrastore Rapide GE Boiler is a compact and versatile 10-liter water heater designed for use in caravans, motorhomes, and other recreational vehicles. This water heater can operate on both gas and electricity, providing flexibility in choosing your energy source. It is designed to work with 10mm diameter flexible water pipes, ensuring compatibility with standard water pipe sizes commonly found in RVs. This product includes a control panel with a 3-meter connecting cable, a white wall cowl for installation, and a safety/drain valve. These components are essential for the proper installation and operation of the water heater. When using the 12V power supply, ignition consumes 0.17A, the heating phase consumes 0.08A, and during standby mode, it draws 0.04A of current. When using a 230V power supply at 850W, the water heater consumes either 3.7A or 5.7A of current. The gas consumption rate for this water heater is 120grams per hour. The water heater without water is just 7.2kg, making it suitable for installation in RVs where weight considerations are important. - Pump pressure: max. 2.8 bar - System pressure: max. 4.5 bar - Type of gas: Liquid gas (propane / butane) - Operating pressure: 30 mbar - Rated thermal output: 1500 W - Gas consumption: 120 g/h - Heating up time from approx. 15 °C to approx. 70 °C (Rapid GE - 10 litres): Gas operation: approx. 31 minutes, Electrical operation: approx. 29 minutes, Gas and electrical operation: approx. 16 minutes - 12V Power consumption: Ignition: 0.17 A, Heating up: 0.08 A, Standby: 0.04 A - 230V Power consumption: Heating up: (3.7 A) 850W / (5.7 A) 1300W Stand-by consumption gas: approx. 70W Key Features 10-liter water heater designed for caravans, motorhomes, and RVs Supplied with standard fittings Operates on both gas and electricity Works with 10mm flexible water pipes commonly found in RVs Comes with a control panel, 3-meter cable, white wall cowl, and safety/drain valve Quickly heats water with gas in approximately 31 minutes and electric in about 29 minutes Brand Truma Type 12 & 230 Volt Voltage Description 12V & 230V Height Description 261mm Width 347mm Depth 360mm Weight 7.2kg Approvals EN 15033 Fuel Butane/Propane 30mbar + 230V Capacity Description 10 Litres Country of Origin Germany

Read more less

The Truma Ultrastore Rapide GE Boiler is a compact and versatile 10-liter water heater designed for use in caravans, motorhomes, and other recreational vehicles. This water heater can operate on both gas and electricity, providing flexibility in choosing your energy source. It is designed to work with 10mm diameter flexible water pipes, ensuring compatibility with standard water pipe sizes commonly found in RVs. This product includes a control panel with a 3-meter connecting cable, a white wall cowl for installation, and a safety/drain valve. These components are essential for the proper installation and operation of the water heater. When using the 12V power supply, ignition consumes 0.17A, the heating phase consumes 0.08A, and during standby mode, it draws 0.04A of current. When using a 230V power supply at 850W, the water heater consumes either 3.7A or 5.7A of current. The gas consumption rate for this water heater is 120grams per hour. The water heater without water is just 7.2kg, making it suitable for installation in RVs where weight considerations are important. - Pump pressure: max. 2.8 bar - System pressure: max. 4.5 bar - Type of gas: Liquid gas (propane / butane) - Operating pressure: 30 mbar - Rated thermal output: 1500 W - Gas consumption: 120 g/h - Heating up time from approx. 15 °C to approx. 70 °C (Rapid GE - 10 litres): Gas operation: approx. 31 minutes, Electrical operation: approx. 29 minutes, Gas and electrical operation: approx. 16 minutes - 12V Power consumption: Ignition: 0.17 A, Heating up: 0.08 A, Standby: 0.04 A - 230V Power consumption: Heating up: (3.7 A) 850W / (5.7 A) 1300W Stand-by consumption gas: approx. 70W Key Features 10-liter water heater designed for caravans, motorhomes, and RVs Supplied with JG Fittings (John guest) Operates on both gas and electricity Works with 10mm flexible water pipes commonly found in RVs Comes with a control panel, 3-meter cable, white wall cowl, and safety/drain valve Quickly heats water with gas in approximately 31 minutes and electric in about 29 minutes Brand Truma Type 12 & 230 Volt Voltage Description 12V & 230V Height Description 261mm Width 347mm Depth 360mm Weight 7.2kg Approvals EN 15033 Fuel Butane/Propane 30mbar + 230V Capacity Description 10 Litres Country of Origin Germany

Read more less

A 31-litre in-vehicle water tank in black featuring four moulded 1/2" BSP fittings for easy connection: a filler inlet, a vent/overflow, and two outlet positions to choose from. This tank is built to accommodate inline or submersible pumps, with a five inch lid providing easy access for maintenance and cleaning. Mounting: Six M8 inserts moulded into the tank for secure attachment to the vehicle. Material: Made from WRAS approved polymer, ensuring suitability for potable water Brand Wydale Plastics Type Low Profile Water Tanks Model T31CBK5 Height Description 460mm Width 176mm Depth 436mm Weight 3.5kg Colour Black Outlet 4 off 1/2" BSP- inlet, vent and 2 outlets Capacity Description 31 Litres Country of Origin United Kingdom   Downloads Dimensional Drawing T31CBK5

Read more less

Flat 75-litre water tank for storing and transporting water as well as various other liquids. The flat design makes it more stable and easier to store in certain spaces compared to cylindrical tanks. The tank's semi-translucent finish allows you to see the liquid level inside the tank. The tank comes with an 8-inch vented screw cap to help regulate pressure inside the tank and facilitate smoother pouring and filling. A 3/4-inch outlet is included, which is a standard size for connecting hoses and other plumbing fittings. Brand Wydale Plastics Type Medium Profile Water Tanks Model T75FNA8PL Height Description 305mm Width 450mm Depth 600mm Weight 6.5kg Colour Transparent Outlet 3/4" BSP Capacity Description 75 Litres Country of Origin United Kingdom DownloadsDimensional Drawing T75FNA8PL

Read more less

Fitting kit for our 31-litre Camper Water Tanks in black or white. Kit contents: 4 x bracket 50 x 55 x 30mm 4 x M8 x 12mm stainless steel socket button head screws 4 x M8 x 25mm washers Brand Wydale Plastics Model CTK31F Country of Origin United Kingdom
