The Tecma Nano toilet comes from the experts in macerating toilets, utilising Turbine Technology to produce a powerful, clog-resistant flush. The Nano combines a high efficiency marine toilet with the smallest design possible, to offer the same comfort of bigger toilets. The 12V Tecma toilet meets requirements for vessels below 50 foot (45 metres). Thetford Marine designed the Nano toilet to be extremely elegant and very flexible to install, thanks to its compact size.
Uses 2 check valves and this combined with a water trap ensures there are no odour issues
Incredibly quiet operation
Can use both raw water and pressure water flush
Leaves a clean, dry bowl after every powerful flush
User-friendly Eco rocker switch (to reduce energy and water consumption) or a smart flush controller with high end flush and tank control features
The performance of the macerator pump meets all quality standards, while the technology inside the toilet has been further developed to keep the sound emission to the lowest level possible, and limiting the water and electrical consumption to minimal levels. The installation, plumbing and wiring is easy and fast, with virtually no maintenance.
Tecma Nano marine toilets can be found on board of: Chaparral Boats, Monterey and Canados.
Specifications:
Weight: 17.6kg (38.8lb)
Outlet Pump: MAC 4 12V
Inlet Device: Solenoid (optional inlet pump)
Control Panel: Premium
Key Features
Italian Ceramic
Nano = 17.6 kg (38.8 lbs)
Wide range of control panels
Silent flush
Low consumption
0.5 - 2 L per flush (0.1 - 0.7 gal)
Specifications
Toilet Flush Water
Fresh Water|Raw Water
Toilet Operation
Electric
Replaces
9-50300
Inlet Outlet
Waste Pump: 1/2" Inlet, 1/4" Outlet, Solenoid: 1/2" Inlet, 1/4" Outlet
Brand
Tecma
Voltage Description
12V DC
Model
Nano
Size
Compact Bowl
Height Description
Overall: 295mm (11.6")
Width
Overall: 370mm (14.6"), Footprint: 190mm (7.5")
Depth
Overall: 446mm (17.5"), Footprint: 320mm (12.6")
Material
Ceramic Bowl
Colour
White
Fuse
30A
Primary Construction
Ceramic
Application
Vessels Below 50 ft (45m)
Tecma 24V DC macerator pump PF.P01B is suitable for use with Tecma Design and Flexi toilet ranges.
Specifications
Brand
Tecma
Voltage Description
24V DC
Tecma 230V AC macerator pump PF.P009 is suitable for use with Tecma Design and Flexi toilet ranges.
Specifications
Brand
Tecma
Voltage Description
230V AC
Tecma Touch SFT Multifunction toilet control panel is made of hi-tech tempered glass, with proximity sensed LED backlighting. Flush is activated by two buttons "Before use" and "After Use". The ultimate touch control panel is design and high-technology combined; with respect for your budget. Tecma T-PF.P11T2 features Smart Flush technology, with mooring and sailing mode, water amount trim, overfill protection and tank monitoring.
The control panel can be used to replace Argent 1P, Argent 2P, Touch 1P, Touch 2P, Premium, Premium Plus and Premium Touch panels.
Tecma Touch SFT Multifunction 2P control panel is suitable for use with Tecma X-Light, X-Light Short, Privilege, Evolution, Breeze, E-Breeze, Silence Plus 2G, Silence Plus 2G Short, Elegance 2G, Elegance 2G Short, Elegance 2G Cut, Elegance 2G Cut Short, Nano, Compass and Compass Short toilets.
Specifications
Brand
Tecma
Height Description
84mm (3.3")
Width
118mm
Depth
Above Surface: 8mm (0.3"), Behind Surface: 21mm (0.8")
Cut Out
70mm x 49mm (2.8" x 1.9")
Application
Tecma X-Light, X-Light Short, Privilege, Evolution, Breeze, E-Breeze, Silence Plus 2G, Silence Plus 2G Short, Elegance 2G, Elegance 2G Short, Elegance 2G Cut, Elegance 2G Cut Short, Nano, Compass, Compass Short
Tecma Touch SFT Multifunction toilet control panel is made of hi-tech tempered glass, with proximity sensed LED backlighting. Flush is activated by two buttons "Before use" and "After Use". The ultimate touch control panel is design and high-technology combined; with respect for your budget. Tecma T-PF.P11T2 features Smart Flush technology, with mooring and sailing mode, water amount trim, overfill protection and tank monitoring.
The control panel can be used to replace Argent 1P, Argent 2P, Touch 1P, Touch 2P, Premium, Premium Plus and Premium Touch panels.
Tecma Touch SFT Multifunction 2P control panel is suitable for use with Tecma X-Light, X-Light Short, Privilege, Evolution, Breeze, E-Breeze, Silence Plus 2G, Silence Plus 2G Short, Elegance 2G, Elegance 2G Short, Elegance 2G Cut, Elegance 2G Cut Short, Nano, Compass and Compass Short toilets.
Specifications
Brand
Tecma
Height Description
84mm (3.3")
Width
118mm
Depth
Above Surface: 8mm (0.3"), Behind Surface: 21mm (0.8")
Cut Out
70mm x 49mm (2.8" x 1.9")
Application
Tecma X-Light, X-Light Short, Privilege, Evolution, Breeze, E-Breeze, Silence Plus 2G, Silence Plus 2G Short, Elegance 2G, Elegance 2G Short, Elegance 2G Cut, Elegance 2G Cut Short, Nano, Compass, Compass Short
Tecma polyester toilet seat and cover 278FR with soft close, suitable for use with Tecma Silence+ and Silence Plus 2G toilets.
Specifications
Brand
Tecma
Tecma toilet floor fixing bracket kit 896 is suitable for use with Tecma Silence+ and Elegance toilets.
Specifications
Brand
Tecma
Application
Tecma Silence, Elegance
Tecma spare toilet seat hinge set 596 is suitable for use with both Tecma Elegance and Silent Plus polyester seat and cover.
Specifications
Brand
Tecma
Tecma white thermosetting plastic seat and cover T-236TB is suitable for Tecma Nano, Silence and Elegance toilets. The toilet seat and cover measures 35cm long.
Key Features
Modern
Hidden seat
Light
Specifications
Brand
Tecma
Length
350mm
Material
Plastic
Colour
White
Primary Construction
Plastic
Application
Pump Out
The Elegance 12V standard height macerator toilet is the mid sized version of the Tecma family. With 2G features, new design and system improvements the Elegance is compact, effective and comfortable. The macerator and flush hoses are all housed within the toilet making installation easy with no protruding parts to accommodate.
The toilet is supplied with a single push control panel including power LED, soft close seat hinges and 12V solenoid valve. Hidden side fixings enhance the elegant design and easy installation. Smooth surfaces make cleaning easier. Strong thermoset seat and cover. New air inlet incorporated into in the internal hose system improving efficiency across different black water installations.
Key Features
Improved 2nd Generation System
Compact toilet with a small footprint
Easy to clean
Easy to control the water consumption
Fully self contained
Low in maintenance
No need to replace valves and seals
Specifications
Brand
Tecma
Voltage Description
12V DC
Height Description
460mm, Seating: 400mm
Width
370mm
Depth
430mm
Weight
22.5kg
Material
Ceramic Bowl
Colour
White
Primary Construction
Ceramic
Flush System
12v / 24v
