Compact Solution for easy accessibility Compact step underneath the vehicle
Weight of only 5.1 kg
Improved stability under light and heavy loads up to 300 kgs.
Addition of a compact model in the Thule Single Step product line-up
Noise reduction during opening and closing of the step Better stability under load accomplished by reinforcements and design optimizations Conform to the EMV and CE standards.
The formulated quality standards exceed European standards EN1646 A switch for the connection of an optional warning lamp in the vehicles supplied as standard, making it impossible to drive away with the step still out.
Accessories
308200 Relay Kit - Auto retract step on ignition turn on
308812 Control Box - Step automatically slides in & out when door is opened
The AVON brand is synonymous with Quality, Durability, High Performance and Value. By sourcing AVON products from the world’s leading factories, and manufacturing them to our exact specifications, we can ensure a Reliable Stockholding, a Premium Quality Alternative and Exceptional Value.
CATEGORIES:
Electric Vehicles
Forklift
Leisure
Marine
Mobility /Stairlift
Solar Panel Equipment
DIMENSIONS: 151 X 99 X 103mm
Capacity at 20-hour Rate (Ah): 112Cold Cranking Performance (Amps) EN1: 870
Designed for vehicles with standard power demands
For occasional overnight stops where hotel-loads are applied
Superior vibration resistance – V3
E2 Endurance rating – up to 150 cycles (50% DOD)
Fully maintenance free with sealed double lid
End venting for remote exhaust of gases
Low self-discharge rate for extended shelf life
Yuasa YBX Super Heavy Duty batteries feature:
Original equipment (OE) quality, performance & specification
Specially designed & constructed for the rigours of commercial, agricultural & plant vehicle applications
Enhanced safety features including integrated flame arrestor & carrying handles
Case Type
Euro Compact Low D2
Voltage
12V
Capacity at 20-hour Rate (Ah)
112
Cold Cranking Performance (Amps) EN1
870
Mean Weight with Acid (kg)
25.5
Cell Layout
0
Terminal
T1
Water Loss
W3
Charge Retention
C2
Vibration
V3
Endurance
E2
Terminal Type
T1
Length (mm)
346
Width (mm)
173
Height (mm)
234
NCC Class
N/A
Capacity at 20-hour Rate (Ah): 220Cold Cranking Performance (Amps) EN1: 1150
Designed for vehicles with standard power demands
For occasional overnight stops where hotel-loads are applied
V4 vibration resistance & are suitable for end of chassis location
E2 Endurance rating – up to 150 cycles (50% DOD)
Fully maintenance free with sealed double lid
End venting for remote exhaust of gases
Low self-discharge rate for extended shelf life
Yuasa YBX Super Heavy Duty batteries feature:
Original equipment (OE) quality, performance & specification
Specially designed & constructed for the rigours of commercial, agricultural & plant vehicle applications
Enhanced safety features including integrated flame arrestor & carrying handles
Case Type
DIN C
Voltage
12V
Capacity at 20-hour Rate (Ah)
220
Cold Cranking Performance (Amps) EN1
1150
Mean Weight with Acid (kg)
55.8
Cell Layout
3
Terminal
T1
State of Charge Indicator
Yes
Water Loss
W3
Charge Retention
C2
Vibration
V4
Endurance
E2
Terminal Type
T1
Length (mm)
516
Width (mm)
274
Height (mm)
236
NCC Class
N/A
YBX1000 CaCa Batteries
Capacity Ah (20-HR): 45Capacity at 20-hour Rate (Ah): 45Cold Cranking Performance (Amps) EN1: 380
Up to 20,000 engine starts
For vehicles with basic power demands
Yuasa YBX® conventional automotive batteries are:
Original equipment (OE) quality, performance & specification
Fully maintenance free
Supplied charged & ready to fit
Designed with enhanced safety features including integrated flame arrestor & carrying handles
Due to unprecedented demand following the easing of COVID-19 lockdown measures, this product may be supplied without a state of charge indicator and not conform to the level of roll over protection advertised. Product performance and quality are not affected by this. Please check battery labels for specification details.
Case Type
L1
Voltage
12V
Capacity at 20-hour Rate (Ah)
45
Cold Cranking Performance (Amps) EN1
380
Mean Weight with Acid (kg)
11.8
Cell Layout
0
Terminal
T1
Recommended Charge Rate (Amps)
3
Handles
Yes
End-Venting
Yes
Capacity Ah (20-HR)
45
Terminal Type
T1
Length (mm)
207
Width (mm)
175
Height (mm)
190
NCC Class
N/A
Designed for vehicles with basic power demands
High Vibration resistance – V2
E1 Endurance rating – over 80 cycles (50% DOD)
Maintenance free with easy access lid plugs for topping up if required
Yuasa YBX Super Heavy Duty batteries feature:
Original equipment (OE) quality, performance & specification
Specially designed & constructed for the rigours of commercial, agricultural & plant vehicle applications
Enhanced safety features including integrated flame arrestor & carrying handles
Case Type
Euro Compact Low D2
Voltage
12V
Capacity at 20-hour Rate (Ah)
110
Cold Cranking Performance (Amps) EN1
750
Mean Weight with Acid (kg)
27.6
Cell Layout
1
Terminal
T1
Water Loss
W2
Charge Retention
C2
Vibration
V2
Endurance
E1
Terminal Type
T1
Length (mm)
347
Width (mm)
174
Height (mm)
235
NCC Class
N/A
Designed for vehicles with basic power demands
High Vibration resistance – V2
E1 Endurance rating – over 80 cycles (50% DOD)
Maintenance free with easy access lid plugs for topping up if required
Yuasa YBX Super Heavy Duty batteries feature:
Original equipment (OE) quality, performance & specification
Specially designed & constructed for the rigours of commercial, agricultural & plant vehicle applications
Enhanced safety features including integrated flame arrestor & carrying handles
Case Type
Euro Compact High D3
Voltage
12V
Capacity at 20-hour Rate (Ah)
142
Cold Cranking Performance (Amps) EN1
850
Mean Weight with Acid (kg)
35.5
Cell Layout
0
Terminal
T1
Water Loss
W3
Charge Retention
C2
Vibration
V2
Endurance
E1
Terminal Type
T1
Length (mm)
345
Width (mm)
175
Height (mm)
275
NCC Class
N/A
Designed for vehicles with basic power demands
High Vibration resistance – V2
E1 Endurance rating – over 80 cycles (50% DOD)
Maintenance free with easy access lid plugs for topping up if required
Yuasa YBX Super Heavy Duty batteries feature:
Original equipment (OE) quality, performance & specification
Specially designed & constructed for the rigours of commercial, agricultural & plant vehicle applications
Enhanced safety features including integrated flame arrestor & carrying handles
Case Type
Euro Compact High D3
Voltage
12V
Capacity at 20-hour Rate (Ah)
126
Cold Cranking Performance (Amps) EN1
750
Mean Weight with Acid (kg)
34
Cell Layout
1
Terminal
T1
Water Loss
W2
Charge Retention
C2
Vibration
V2
Endurance
E1
Terminal Type
T1
Length (mm)
347
Width (mm)
174
Height (mm)
285
NCC Class
N/A
