All-in-one Lithium Power Supply Includes:
+ 2400Wh LiFePO4 Li-Ion Battery
+ 1440w DC-DC Alternator Charger
+ 1440w MPPT Smart Solar Charger
+ 2400w Hookup Charging
+ 4000w Inverter for 230v – 8000w peak!
Headline Specifications
230V Output
Power: 4000W (continuous)
Peak: 8000W
4.3” HD multi-color display (800×480 px)
Bluetooth + 4G remote monitoring via mobile app
12 V Output
Continuously: 60A
Built-in Li-Ion Battery
Integrated heating film for low-temperature operation
Efficient Energy: 2.4kWh
Capacity: 200Ah
Integrated insulation monitoring. Leakage protection.
Battery management system (BMS)
Charging
Alternator: Inbuilt +1440W (48v 30A)
Solar Input: 2,400W (48V, 50A)
Mains: 1704W
Full Specifications
Product weight: 43 kg
Product dimensions: (HxWxL) 490 x 380 x 215 mm
Battery type: LiFePO4 (Lithium Iron Phosphate)
Battery chemistry: LiFePO4 48v
Battery capacity: 2400Wh
Connection 230 VAC: 1x Front, 1x Rear Schuko Power Socket
Cooling: Forced air (fan)
IP rating: IP20
230 V AC input ECO power cable
230 V AC output Schuko power socket
12 V DC input Anderson SA50A
12 V DC output Anderson SA50A
Additional information
| Weight |
43 kg |
| Dimensions |
490 × 380 × 210 mm |
| AC: Output Cont (w) |
4000
|
| DC: Output (A) |
60
|
| Alternator: Charging (w) |
1440
|
| Battery: Capacity (kWh) |
2.4
|
| Battery: Capacity (ah 12v Equivalent) |
200
|
| Inverter: Peak (w) |
8000
|
| AC: Charging (w) |
1440
|
| MPPT: Input Max (w) |
2400
|
| MPPT: Max (v) |
60
|
| Battery: Chemistry |
LiFePO4
|
Please click the link below to view Zeliox Neo 400 electrics video:
https://youtu.be/KeOiQQrYwc0?si=UfAlQORL9fk6HzZQ
