Clayton Power Lithium Power Supply II 2000W UK (CL2205)
Clayton Power Lithium Power Supply II 2000W UK (CL2205)
A powerful and compact Lithium Power Supply (LPS) built to provide power to 230V AC and 12V DC appliances without the complexities of additional equipment.
The LPS II 2000 model has a built-in 1kWh lithium-ion battery, 230V sine wave inverter, booster (charging from alternator), 400W MPPT charge controller (charging from solar panels), intelligent charger (charging from mains), relays etc.
This Lithium Power Supply offers flexible charging options. The built-in booster allows regeneration with 500W from any alternator. Connected to mains, the built-in intelligent charger regenerates with 750W. Connect solar panels directly - the built-in solar charge controller also allows regeneration from the sun with 400W.
The lithium battery capacity of 1kWh means that you can run an application with a consumption of 1000W in one hour, 500W for two hours and 250W for four hours. The battery can handle 2000 cycles - which is usually equivalent to 10 years of use.
For the LPS II remote control (supplied separately), see product code CP-RL1802. This remote allows the user to view state of charge, status and active jump start function.
For the LPS II mounting bracket (supplied separately), see product code CP-AL2001.
230 V/50 Hz output
- Peak: 3000W
- Power: 2000W
12 V DC output
- 60 Seconds: 270 A
- Continuously: 180 A
Built-in Li-Ion Battery
- Capacity: 1320 Wh (100 Ah)
- Efficient energy: 1kWh
Charging
Alternator: 500W / SC: 1000W
Solar panels: 400W
Mains: 750W
Brand | Clayton Power |
Type | Power Supply Units |
Model | CL2205 |
Height Description | 256mm |
Width | 277mm |
Depth | 409mm |
Weight | 22.5kg |
Output | 230 V/50 Hz Output: Peak: 3000 W, Power: 2000 W |
Wattage | Charging: Alternator: 500 W / SC: 1000 W, Mains: 750 W, Solar Panels: 400 W |
Operating Temperature | -20°C - 50°C |
Amps Description | 12V Output: 60 Seconds: 270 A, Continously: 180 A |
Capacity Description | Built-in Li-Ion Battery: 1320 Wh (100 Ah) |
Country of Origin | Denmark |
