Features of the - Victron BlueSolar PWM Light Charge Controller 12/24V 30A Load output with low battery voltage disconnect function.  Lighting control function, one timer only.  Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.  Three stage battery charging (bulk, absorption, float), not programmable.  Load output protected against over load and short circuit.  Protected against reverse polarity connection of the solar array and/or battery.  Day/night timing options: see manual for details.

Read more less

Features of the - Victron BlueSolar PWM Light Charge Controller 12/24V 20A Load output with low battery voltage disconnect function.  Lighting control function, one timer only.  Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.  Three stage battery charging (bulk, absorption, float), not programmable.  Load output protected against over load and short circuit.  Protected against reverse polarity connection of the solar array and/or battery.  Day/night timing options: see manual for details.

Read more less

Features of the - Victron BlueSolar PWM Light Charge Controller 12/24V 20A Load output with low battery voltage disconnect function.  Lighting control function, one timer only.  Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.  Three stage battery charging (bulk, absorption, float), not programmable.  Load output protected against over load and short circuit.  Protected against reverse polarity connection of the solar array and/or battery.  Day/night timing options: see manual for details. For more info please download this link>> Pdf

Read more less

Features of the - Victron BlueSolar PWM Pro Charge Controller 12/24V 5A The BlueSolar PWM-Pro series is ready for use with its default settings.  It also is fully programmable:  With help of a computer and software  With the dedicated BlueSolar Pro Remote Panel (see features below)  Features  Lighting control function, fully programmable.  Three stage battery charging (bulk, absorption, float), fully programmable.  Integrated battery monitor function (Remote Panel needed to display state of charge).  Load output with low voltage disconnect and manual control (default setting).  Optional external temperature sensor. – Load output protected against over load and short circuit.  Protected against reverse polarity connection of the solar array and/or battery.  Day/night timing options  See Remote Panel manual for details.

Read more less

Features of the - Victron BlueSolar PWM Light Charge Controller 12/24V 10A Load output with low battery voltage disconnect function.  Lighting control function, one timer only.  Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.  Three stage battery charging (bulk, absorption, float), not programmable.  Load output protected against over load and short circuit.  Protected against reverse polarity connection of the solar array and/or battery.  Day/night timing options: see manual for details. For more info please downlowd this link>>

Read more less

Victron BlueSolar PWM Light Charge Controller 12/24V 5A Load output with low battery voltage disconnect function.  Lighting control function, one timer only.  Two digit seven segment display for quick and easy setting of the load output functionality, including timer setting.  Three stage battery charging (bulk, absorption, float), not programmable.  Load output protected against over load and short circuit.  Protected against reverse polarity connection of the solar array and/or battery.  Day/night timing options: see manual for details.

Read more less

Especially in the case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.  Advanced Maximum Power Point Detection in case of partial shading conditions If partial shading occurs, two or more maximum power points (MPP) may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum MPP.  Outstanding conversion efficiency  No cooling fan. Maximum efficiency exceeds 99%.  Flexible charge algorithm  Fully programmable charge algorithm, and eight pre-programmed algorithms, selectable with a rotary switch (see manual for details).  Extensive electronic protection  Over-temperature protection and power derating when temperature is high. PV short circuit and PV reverse polarity protection. PV reverse current protection.  Internal temperature sensor  Compensates absorption and float charge voltage for temperature.  Optional external battery voltage, temperature and current sensing via Bluetooth  A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature (and current, in case of a BMV 712 or a SmartShunt) to one or more BlueSolar Charge Controllers. (VE.Direct Bluetooth Smart dongle needed)  VE.Can: the multiple controller solution  Up to 25 units can be synchronised with VE.Can  VE.Direct or VE.Can  For a wired data connection to a Colour Control GX, other GX products, PC or other devices  Remote on-off  To connect for example to a VE.BUS BMS.  Programmable relay  Can be programmed to trip on an alarm, or other events.  Optional: SmartSolar pluggable LCD display  Simply remove the rubber seal that protects the plug on the front of the controller, and plug-in the display. Files

Read more less

A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life. The SmartSolar charge controller will even recharge a severely depleted battery. It can operate with a battery voltage as low as 0 Volts, provided the cells are not permanently sulphated or otherwise damaged.  Features of the -  Victron Energy Smart Solar MPPT 150V/45A - (12/24/48V)  Specification Summary Battery voltage: 12/24/48V Auto Select Rated charge current: 45A Nominal PV power, 12V: 650W Nominal PV power, 24V: 1300W Max. PV short circuit current: 50A Automatic load disconnect: Yes Max. PV open circuit voltage: 150V Bluetooth Smart built-in  The wireless solution to set-up, monitor, update and synchronise SmartSolar Charge Controllers.  VE.Direct  For a wired data connection to a Colour Control GX, other GX products, PC or other devices  Ultrafast Maximum Power Point Tracking (MPPT)  Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.  Advanced Maximum Power Point Detection in case of partial shading conditions  If partial shading occurs, two or more maximum power points may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum MPP.  Outstanding conversion efficiency  No cooling fan. Maximum efficiency exceeds 98%. Full output current up to 40°C (104°F).  Flexible charge algorithm  Fully programmable charge algorithm (see the software page on Victron), and eight pre-programmed algorithms, selectable with a rotary switch (see manual for details).  Extensive electronic protection  Over-temperature protection and power derating when temperature is high.  PV short circuit and PV reverse polarity protection. PV reverse current protection.  Internal temperature sensor   Compensates absorption and float charge voltage for temperature.  Optional external battery voltage and temperature sensing via Bluetooth  A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature to one or more SmartSolar Charge Controllers.  Fully discharged battery recovery function  Will initiate charging even if the battery has been discharged to zero volts. Will reconnect to a fully discharged Li-ion battery with integrated disconnect function.

Read more less

The Victron range of SmartSolar charge controllers maximize this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life. Specification Summary A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, SmartSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. SmartSolar maintains battery health, extending its life. The SmartSolar charge controller will even recharge a severely depleted battery. It can operate with a battery voltage as low as 0 Volts, provided the cells are not permanently sulphated or otherwise damaged.  Features of the -  Victron Energy Smart Solar MPPT 150V/35A - (12/24/48V)  Specification Summary Battery voltage: 12/24/48V Auto Select Rated charge current: 35A Nominal PV power, 12V: 500W Nominal PV power, 24V: 1000W Max. PV short circuit current: 40A Automatic load disconnect: Yes Max. PV open circuit voltage: 150V Bluetooth Smart built-in  The wireless solution to set-up, monitor, update and synchronise SmartSolar Charge Controllers.  VE.Direct  For a wired data connection to a Colour Control GX, other GX products, PC or other devices  Ultrafast Maximum Power Point Tracking (MPPT)  Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.  Advanced Maximum Power Point Detection in case of partial shading conditions  If partial shading occurs, two or more maximum power points may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum MPP.  Outstanding conversion efficiency  No cooling fan. Maximum efficiency exceeds 98%. Full output current up to 40°C (104°F).  Flexible charge algorithm  Fully programmable charge algorithm (see the software page on Victron), and eight pre-programmed algorithms, selectable with a rotary switch (see manual for details).  Extensive electronic protection  Over-temperature protection and power derating when temperature is high.  PV short circuit and PV reverse polarity protection. PV reverse current protection.  Internal temperature sensor   Compensates absorption and float charge voltage for temperature.  Optional external battery voltage and temperature sensing via Bluetooth  A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature to one or more SmartSolar Charge Controllers.  Fully discharged battery recovery function  Will initiate charging even if the battery has been discharged to zero volts. Will reconnect to a fully discharged Li-ion battery with integrated disconnect function.

Read more less

The Victron MPPT controller will adjust its input voltage to harvest the maximum power from the solar array and then transform this power to supply the varying voltage requirement, of the battery plus load. Thus, it essentially decouples the array and battery voltages so that there can be, for example, a 12 volt battery on one side of the MPPT charge controller and a large number of cells wired in series to produce 36 volts on the other. To fully exploit the potential of the MPPT controller, the array voltage should be substantially higher than the battery voltage. The MPPT controller is the solution of choice for higher power systems because of the lowest overall system cost due to smaller cable cross sectional areas. It will also harvest substantially more power when the solar cell temperature is low (below 45°C), or very high (above 75°C), or when irradiance is very low. Ultrafast Maximum Power Point Tracking (MPPT)  Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.  Advanced Maximum Power Point Detection in case of partial shading conditions  If partial shading occurs, two or more maximum power points may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum MPP.  Outstanding conversion efficiency  No cooling fan. Maximum efficiency exceeds 98%. Full output current up to 40°C (104°F).  Flexible charge algorithm  Fully programmable charge algorithm (see the software page on our website), and eight preprogrammed algorithms, selectable with a rotary switch (see manual for details).  Extensive electronic protection Over-temperature protection and power derating when temperature is high. PV short circuit and PV reverse polarity protection. PV reverse current protection. Internal temperature sensor Compensates absorption and float charge voltage for temperature.  Real-time data display options  - Color Control GX or other GX devices:  BatteryLife: intelligent battery management by load shedding. For more info please download the link>> Pdf

Read more less

These ultra-fast, Maximum Power Point Tracking (MPPT), solar charge controllers are Bluetooth accessible via either built in Bluetooth or the Victron Energy Bluetooth dongle. Utilising the free VictronConnect app many parameters can be viewed and set, such as battery voltage, solar history, load output, flexible battery charge algorithms plus day/night timing and light dimming options. These advanced MPPTs also include Advanced Maximum Power Point Detection in case of partial shading conditions. Specification Summary Battery voltage: 12/24V Auto Select Rated charge current: 30A Nominal PV power, 12V: 440W Nominal PV power, 24V: 880W Max. PV short circuit current: 35A PV open circuit voltage: 100V Features Bluetooth Smart built-in  The wireless solution to set-up, monitor, update and synchronise SmartSolar Charge Controllers.  VE.Direct For a wired data connection to a Color Control GX, other GX products, PC or other devices  Ultrafast Maximum Power Point Tracking (MPPT)  Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.  Advanced Maximum Power Point Detection in case of partial shading conditions  If partial shading occurs, two or more maximum power points may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum MPP.  Outstanding conversion efficiency  No cooling fan. Maximum efficiency exceeds 98%. The full output current up to 40°C (104°F).  Flexible charge algorithm  Fully programmable charge algorithm (see the software page on our website), and eight pre-programmed algorithms, selectable with a rotary switch (see manual for details).  Extensive electronic protection  Over-temperature protection and power derating when temperature is high. PV short circuit and PV reverse polarity protection. PV reverse current protection.  Internal temperature sensor  Compensates absorption and float charge voltage for temperature. Optional external battery voltage and temperature sensing via Bluetooth A Smart Battery Sense or a BMV-712 Smart Battery Monitor can be used to communicate battery voltage and temperature to one or more Smart Solar Charge Controllers.

Read more less

A solar charger gathers energy from your solar panels, and stores it in your batteries. Using the latest, fastest technology, BlueSolar maximises this energy-harvest, driving it intelligently to achieve full charge in the shortest possible time. BlueSolar maintains battery health, extending its life. Specification Summary Battery voltage: 12/24V Auto Select  Rated charge current: 15A   Nominal PV power, 12V: 220W  Nominal PV power, 24V: 440W  Max. PV short circuit current: 15A   Automatic load disconnect: Yes Max.  PV open circuit voltage: 100V Features Bluetooth Smart built-in: dongle not needed The wireless solution to set-up, monitor and update the controller using Apple and Android smartphones, tablets or other devices. VE.Direct For a wired data connection to a Colour Control panel, PC or other devices Ultra-fast Maximum Power Point Tracking (MPPT) Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers. Load output Over-discharge of the battery can be prevented by connecting all loads to the load output. The load output will disconnect the load when the battery has been discharged to a pre-set voltage. Alternatively, an intelligent battery management algorithm can be chosen: see Battery Life. Battery Life: intelligent battery management When a solar charge controller is not able to recharge the battery to its full capacity within one day, the result is often that the battery will continually be cycled between a ‘partially charged’ state and the ‘end of discharge’ state. This mode of operation (no regular full recharge) will destroy a lead-acid battery within weeks or months. The Battery Life algorithm will monitor the state of charge of the battery and, if needed, day by day slightly increase the load disconnect level (i.e. disconnect the load earlier) until the harvested solar energy is sufficient to recharge the battery to nearly the full 100%. From that point onwards the load disconnect level will be modulated so that a nearly 100% recharge is achieved about once every week. Programmable battery charge algorithm See the software section on Victron Energy's website for details Day/night timing and light dimming option See the software section on Victron Energy's website for details Programming, real-time data and history display options - Modern Apple and Android smartphones, tablets, macbooks and other devices: see the VE.Direct Bluetooth Smart dongle and the MPPT app discovery sheet for screenshots. - Colour Control panel

Read more less
