F790 KEY FEATURES
- Main dash cam unit
- Mount
- Hardwiring cable
- Adhesive cable holder (3ea)
- MicroSD memory card with adapter (consumable)
- Quick Start Guide/Warranty Card
Specification:
- CAMERA: CMOS 2.1M
- RESOLUTION Front: Full HD 1080P (1920 X 1080) Rear: Full HD 1080P (1920 X 1080)
- VIEWING ANGLE Front: 140° (Diagonal) Rear: 160° (Diagonal)
- CAPACITY: Micro SD Card 16GB/32GB/64GB/128GB UHS-I
- SENSOR: 3-Axis Accelerometer G-Sensor (3D, ±3G)
- GPS: Built-in GPS
- WI-FI: Built-in Wi-Fi (2.4GHz / 5GHz)
- POWER: DC 12/24V Built-in Super Capacitor
- Download Full Specifications
THINKWARE DASH CAM PLUGIN
A simple solution for mounting and dismounting your dash cam while maintaining a sense of sharpness and sleekness in design.
SECURE CONNECTING MECHANISM
The dash cam perfectly clips into Thinkware Dash Cam Plugin. It uses a connecting mechanism embedded within the connector cradle for a secure and safe connection.
CLEAN CABLE INTEGRATION
The power cable and GPS module are connected on Thinkware Dash Cam Plugin. This reduces the risk of overheating as the power connector is separated from the main unit.
THINKWARE DASH CAM LINK APP
The camera’s built-in Wi-Fi allows it to connect to the Dash Cam Link App, letting you easily view, download, delete or share footage directly from your smartphone.
Thinkware Dash Cam Link provides easy access to your Thinkware Dash Cam. Share the best driving videos on social media by simply downloading your dashcam footage into your smartphone’s photo album. Replay your latest driving videos and manage your dash cam’s settings all in one app.
HIGH DEFINITION VIDEO QUALITY
SUPER NIGHT VISION 3.0
Record night-time drives with true colours and minimal noise thanks to Thinkware’s latest advancements in low-light recording technology that surpasses its predecessors’ night time performance. The dash cam uses a combination of Digital Overlap High Dynamic Range (DOL HDR) and Noise Reduction technology to effectively reduce noise and lens flare effects that typically affect night-time footage.
DEWARPING VIDEO TECHNOLOGY
HIGH-EFFICIENCY VIDEO CODING FORMAT
HEVC has a compression rate of 1.7 times higher than the standard Advanced Video Coding format in dash cams.
Hence, you get outstanding video quality with less consumption of memory space.
PARKING SURVEILLANCE MODE
Parking mode is a feature of dash cams that are either hardwired or using the OBD2 Connector. This allows them to continue recording while your car is parked and turned off. All Thinkware dashcams continuously monitor the health of the vehicle’s battery and will shut down if it detects any issues.
Please note: A hardwire or OBDII cable installation is required for Parking Mode functionality
Motion Detection
Monitor and capture any motion around the vehicle for potential vandalism attempts.
Impact Detection
Monitor any impact to the vehicle while it is parked to catch any hit-and-run driver in the act while you are away.
TIME LAPSE PARKING MODE
ENERGY SAVING MODE 2.0
SAFETY CAMERA ALERTS
Get audio warnings from your cash cam when approaching a wide variety of road safety cameras*.
Thinkware Dash Cams provides active alert for these 5 types of road safety cameras while still recording videos.
*UK speed camera (Cyclops) database with regular free updates
RED LIGHT WARNING SYSTEM
SPEED CAMERA WARNING SYSTEM
RED LIGHT & SPEED CAMERA WARNING SYSTEM
AVERAGE SPEED WARNING SYSTEM
MOBILE ZONE WARNING SYSTEM
ADVANCED DRIVER ASSISTANCE SYSTEM (ADAS)
FORWARD COLLISION WARNING SYSTEM
(FCWS/ UFCWS)
Warns the driver of impending road hazards.
FRONT VEHICLE DEPARTURE WARNING
(FVDW)
LANE DEPARTURE WARNING SYSTEM
(LDWS)
Detects if the vehicle is veering off the driving lane.
GPS MAPPING
With GPS, all Thinkware dash cams can record the vehicle’s driving speed and provide its precise location and routes identification on the map. The GPS Tracker helps you to accurately assess the details of the surrounding area. The PC/Mac viewer can then provide you with the vehicle speed and the time of a collision, and the severity of any impacts.
PC / MAC VIEWER
The intuitive and simple-to-use interface of Thinkware Dash Cam allows you an easy and convenient viewing of your recorded videos. Through PC or Mac viewer, you can playback and download recorded videos. You can also change the dash cam settings, format the memory card, or install updates with just a few clicks on the viewer.
MULTIPLE RECORDING MODES
Please ensure that your F790 Dash Cam firmware is up-to-date via the smartphone app to fully benefit from these modes.
CONTINUOUS RECORDING MODE
This mode is activated automatically when you start the engine. Recorded videos are saved in one-minute segments with an auto-looping mechanism.
INCIDENT RECORDING MODE
The Active Impact Monitoring System will automatically store the video data ten seconds prior to and after a collision registered by the 3-axis G-Sensor.
MANUAL RECORDING MODE
Similar to a video camera, you can use the Manual Recording Mode to capture events that occur in front of your vehicle whether or not it is in motion.
FAIL-SAFE RECORDING
In the event that the power gets disconnected after an accident, the fail-safe recording uses the Super Capacitor for backup power to ensure safe storage of any recording in progress.
HIGH DYNAMIC RANGE
Capture maximum image detail. The dash cam automatically corrects exposure levels with the multi-exposure feature, enabling the unit to get a clean image even when light levels are too high or low.
FORMAT FREE TECHNOLOGY
Avoid corrupt memory cards and the slow process of having to reformat your SD Cards with the free flowing recording system.
One of the most common issues with a Dash cam’s reliability is the SD card, these cards are continuously overwritten and often become corrupt if not formatted often. This normally means that you have to remove the SD card and put it into a computer to reformat it. Thinkware have overcome this vulnerability by making the dashcam pre-allocate the memory, avoiding the need to format the SD card on a regular basis and making the footage easily viewable on our Thinkware viewer software.
HIGH-TEMPERATURE PROTECTION SYSTEM
Protects your dashboard camera from overheating and causing potentially irreversible damage to it or its data.
The specially designed heat discharge construction and the built-in thermal sensor of the dash cam protects the device and its data against intense heat by automatically turning it off to prevent overheating. All Thinkware cameras use a Super Capacitor, designed with Temperature Protection, for an emergency power source in the event of a crash or sudden power loss, allowing the unit to save the last 10 seconds of an incident.
ADDITIONAL CAMERAS
Thinkware Dash Cams have pioneered front and rear (2 Channel) dashcam systems for many years.
Choose from three options for a secondary camera to best suit your needs.
REAR CAMERA
Designed to be mounted inside the vehicle on the rear window facing out.
A 160° wide-angle lens captures all footage from behind the vehicle in 720p detail.
A great enhancement to parking mode.
INTERNAL INFRARED
Designed to be mounted on the front windscreen, facing into the vehicle.
A 140° wide-angle lens records footage of all occupants, including the front seat, in all lighting conditions.
Ideal coverage for taxis and rideshare drivers.
EXTERNAL REAR
Our external camera is fully waterproof and dustproof to an IP68 rating.
Designed to mount horizontal, vertical or inverted, the fully adjustable bracket will always point the 160° wide-angle lens in the right direction.
Complete with infrared capabilities to record in all lighting conditions. Highly recommended for use on commercial vehicles without rear windows.
MUX BOX
Need even more from your camera?
Add the optional Mux Box to allow up to 4 additional cameras be added to your front facing dash cam instead of one rear unit.
Simply connect the Mux box to the Rear camera feed and then add your choice of side cams, rear external, rear internal or internal infrared cameras.
The perfect solution for passenger cars, light commercial vehicles and HGVs.
